A4 - CYCLONIC PREFILTER
CLEAN
The cleaning interval is given as a guide, however the prefilter must be emptied as soon
as impurities reach the MAXI level on the tank.
- Loosen nut 1 (Fig. A4), remove cover 2 (Fig. A4) and empty the tank.
- Clean the prefilter unit with a clean dry cloth and reassemble the unit.
When cleaning, take care not to let impurities into the dry air filter.
A5 - TRANSMISSION OIL LEVEL
CHECK
Park the lift truck on level ground with the jib raised, the I.C. engine cold and stopped.
Carry out the control within 5 minutes of the i.c. engine being stopped.
- Remove the plastic cap 1 (Fig. A5).
- Remove the dipstick 2 (Fig. A5).
- Wipe the dipstick and check the correct level between the two MIN and MAX marks.
- If necessary, add oil (See chapter : E3 - TRANSMISSION OIL in paragraph : 3 -
MAINTENANCE).
A6 - TYRES PRESSURE AND WHEEL NUTS TORQUE
CHECK
- Check the condition of the tyres, to detect cuts, protuberances, wear, etc.
- Check the torque load of the wheel nuts (See fig. A6). Non compliance with this
instruction can cause damage and rupture to the wheel bolts and distortion to the
wheels.
- Check and adjust the tyre pressures if necessary (See chapter : CHARACTERISTICS
paragraph : 2 - DESCRIPTION).
Check that the air hose is correctly connected to the tyre valve before inflating and
keep all persons at a distance during inflation. Respect the recommended tyre
pressures given.
3 - 11
2
MLT 629/730 Série A
MLT 629/730 Turbo Série A
MLT 629/633/730 -120 LS Série A
MLT 633/730 LS Turbo Série A
MT 732/932 Série A
MT 732 Turbo Série A
A5
1
A5
1
2
MLT 633/730 -120 LS POWERSHIFT Série A
MLT 730 Turbo POWERSHIFT Série A
A4
1
2
630 ± 15 %
N.m
630 ± 15 %
N.m
A6
WHEEL NUTS
TIGHTENING TORQUE
FRONT TYRES
REAR TYRES
