Manitou MLT 730 User Manual

2 - 50
3 - CONTROL AND SIGNAL LIGHTS PANEL
CONTROL INSTRUMENTS
A - HOURMETER AND REV COUNTER MLT 629/730 Série A
MLT 629/730 Turbo Série A
MLT 629/633/730 -120 LS Série A
MLT 633/730 LS Turbo Série A
MLT 633/730 -120 LS POWERSHIFT Série A
MLT 730 Turbo POWERSHIFT Série A
A - HOURMETER MT 732/932 Série A
MT 732 Turbo Série A
B - I.C. ENGINE WATER TEMPERATURE
Temperature zone B1 - Blue zone (0° - 50°)
B2 - Green zone (50° - 100°)
B3 - Black/red zone (100° - 105°)
B4 - Red zone (105° - 120°)
NOTE : Red indicator light “E” comes on between zone B3 and B4.
C - FUEL LEVEL
Red zone C1 indicates that you are using the reserve supply and that time of use is
limited.
SIGNAL LIGHTS
When activating the electrical system of the lift truck, all the red lamps and the panel's
buzzer must light to indicate their good working order. If one of the red lamps or the
buzzer does not function, carry out the necessary repairs.
D - RED TRANSMISSION OIL PRESSURE LAMP
MLT 629/730 Série A
MLT 629/730 Turbo Série A
MLT 629/633/730 -120 LS Série A
MLT 633/730 LS Turbo Série A
MT 732/932 Série A
MT 732 Turbo Série A
The lamp and the buzzer come on when the pressure in the transmission, when driving
forward, is abnormally low. Stop the lift truck and look for the cause (Insufficient
transmission oil level, internal leak in the transmission, etc.).
NOTE : The signal light operates in forward travel conditions only, the signal should not be taken into account when the engine
is running at idle or is stopped.
D - RED CLUTCH PRESSURE LAMP
MLT 633/730 -120 LS POWERSHIFT Série A
MLT 730 Turbo POWERSHIFT Série A
The lamp and buzzer come on when there is an abnormal lowering of pressure in the transmission. Stop the lift truck and find
out what is causing it (Insufficient transmission oil level, internal leak in the transmission, etc).
NOTE : Since this light only operates while driving, do not take the information into consideration when the lift truck has stopped
or is idling.
E - RED TRANSMISSION OIL TEMPERATURE LAMP
The lamp and the buzzer come on when the converter oil temperature is abnormally high. Stop the lift truck and look for the
cause of this overheating.
D E F G
H I J K
L M N O
B1 B2 B3 B4
C1
MLT . . . Série A
MT ...Série A
B1 B2 B3 B4
C1
C
A
B
B
A
C
