2 - 51
F - RED BRAKING OIL LEVEL LAMP
If the lamp and the buzzer come on, when the lift truck is running, stop the I.C. engine immediately and check the braking oil
level. In the event of an abnormal dropping of the level, consult your dealer.
G - RED PARKING BRAKE LAMP
This lamp comes on when the parking brake is applied.
H - RED ALTERNATOR CHARGE LAMP
If the lamps E - F - H - I - J - K and the buzzer come on, when the lift truck is running, stop the I.C. engine immediately and
check the electrical circuit as well as the alternator belt.
I - RED I.C. ENGINE OIL PRESSURE LAMP
If the lamp and the buzzer come on when the lift truck is running, stop the I.C. engine immediately and look for the cause (See
oil level in engine crankcase).
J - RED I.C. ENGINE WATER TEMPERATURE LAMP
If the lamp and the buzzer come on when the lift truck is running, stop the I.C. engine immediately and investigate the cooling
system for the cause of the malfunction.
K - RED LAMP - AIR FILTER OR HYDRAULIC RETURN FILTER CLOGGED
The lamp and buzzer come on when the air filter cartridge or the hydraulic return oil filter cartridge is clogged up. Stop the lift
truck and carry out the necessary repairs (See cleaning and replacement requirements in chapter : FILTERS CARTRIDGES
AND BELTS in paragraph : 3 - MAINTENANCE).
L - GREEN INDICATOR LAMP
M - GREEN SIDELIGHTS LAMP
N - GREEN LOW BEAM LAMP
O - BLUE MAIN BEAM LAMP
4 - L
OAD STATUS INDICATOR
The load status indicator allows the user to know at any moment if the lift truck is at the
maximum authorised load limit.
OPERATION
When the lift truck is switched on a control test is automatically carried out.
- Correct operation : All leds and the sound alarm function continuously for 2 seconds.
- Faulty operation : All leds and sound alarm function intermittently (Stop the lift truck
and consult your dealer, never attempt a repair yourself).
A - LEDS (VISUAL ALARM) (FIG. A)
A1 - 4 green leds : The lift truck is operating safely.
A2 - 2 yellow leds : The lift truck is nearing the maximum authorised load limit.
A3 - 1 red led : The lift truck is at the maximum authorised load limit - slowly intermittent sound alarm is triggered.
A4 - 1 red led : The lift truck is overloaded - speedy intermittent sound alarm is triggered. Carry out positive hydraulic
movements in the following order : raise and retract the jib.
B - SOUND ALARM SWITCH (FIG. A)
Allows the sound alarm to be used or switched OFF. When not in use, the red signal light B1 shows that the sound alarm has
been cut off and that only the visual alarm is working.
A
B
C
B1
A4
A3
A2
A2
A1
A1
A1
A1
A
