3-11
A = ADJUST, C = CHECK, G = GREASE, N = CLEAN,
P = BLEED, R = REPLACE, V = DRAIN
PAGE
(1)
DAILY OR EVERY 10
HOURS SERVICE
EVERY 50 HOURS
SERVICE
EVERY 250 HOURS
SERVICE
EVERY 500 HOURS
SERVICE OR 6
MONTHS
EVERY 1000 HOURS
SERVICE OR 1 YEAR
EVERY 2000 HOURS
SERVICE OR 2
YEARS
EVERY 4000 HOURS
SERVICE
OCCASIONALLY
BRAKE
Brake system pressure
C* <<< <<<
Brake A* <<< <<<
Brake solenoid valve filter N* <<< <<<
OVERHEAD GUARD
Windscreen washer liquid level
3-16 C C <<< <<< <<< <<< <<<
Seat belt 3-26 C <<< <<<
Condition of the rear view mirrors C* <<< <<<
Structure C* <<< <<<
Raising the overhead guard in the event of a breakdown 3-32 XXX
CAB (OPTION)
Windscreen washer liquid level
3-16 C C <<< <<< <<< <<< <<<
Cab door 3-16 G G <<< <<< <<< <<< <<<
Seat belt 3-26 C <<< <<<
Condition of the rear view mirrors C* <<< <<<
Structure C* <<< <<<
Lift the cab in case of failure 3-32 XXX
ELECTRICITY
Condition of wiring harness and cables
C* <<< <<<
Lights and signals (OPTION) C* <<< <<<
Warning indicators C* <<< <<<
Battery failure 3-33 R
Front headlights (OPTION) 3-33 A
REAR AXLE
MSI 20 T Série 2-E3 - MSI 20 T BUGGIE Série 2-E3
MSI 25 T Série 2-E3 - MSI 25 T BUGGIE Série 2-E3
MSI 30 T Série 2-E3 - MSI 30 T BUGGIE Série 2-E3
MSI 35 T Série 2-E3 - MSI 35 T BUGGIE Série 2-E3
Swivel pins 3-17 G G <<< <<< <<< <<< G/C*
Steering connecting rod 3-17 G G <<< <<< <<< <<< <<<
Rear axle oscillation 3-17 G G G/C* <<<
Steering C* <<<
Rear axle C**
MH 20-4 T BUGGIE Série 2-E3
MH 25-4 T BUGGIE Série 2-E3
Wheel motor pivots 3-17 G G <<< <<< <<< <<< G/C*
Steering connecting rod 3-17 G G <<< <<< <<< <<< <<<
Rear axle oscillation 3-17 G G <<< <<< <<< G/C* <<<
Steering C* <<<
Rear axle C*
CHASSIS
Structure
C* <<< <<<
Bearings and articulation rings C* <<<
ATTACHMENTS
Forks wear
C* C* <<< <<< <<<
Attachment carriage C* <<< <<<
Condition of attachments C* <<< <<<
LIFT TRUCK
Tow the lift truck
3-34/35 XXX
Sling the lift truck 3-36 XXX
Transport the lift truck on a platform 3-37 XXX
(*): Consult your dealer.
(**): To be performed after the first 50 hours of operation and then every 500 hours..
