3-10
SERVICING SCHEDULE
(1): MANDATORY 500 HOUR OR 6 MONTH SERVICE
This service must be carried out after approximately the first 500 hours of operation or within the 6 months following the start-up of the machine
(whichever occurs first).
A = ADJUST, C = CHECK, G = GREASE, N = CLEAN,
P = BLEED, R = REPLACE, V = DRAIN
PAGE
(1)
DAILY OR EVERY 10
HOURS SERVICE
EVERY 50 HOURS
SERVICE
EVERY 250 HOURS
SERVICE
EVERY 500 HOURS
SERVICE OR 6
MONTHS
EVERY 1000 HOURS
SERVICE OR 1 YEAR
EVERY 2000 HOURS
SERVICE OR 2
YEARS
EVERY 4000 HOURS
SERVICE
OCCASIONALLY
I.C. ENGINE
I.C. engine oil level
3-12 C C <<< <<< <<< <<< <<< <<<
Cooling liquid level
3-12 C C <<< <<< <<< <<< <<< <<<
Fuel level
3-13 C C <<< <<< <<< <<< <<< <<<
Cyclonic pre-filter (OPTION)
3-13 N N <<< <<< <<< <<< <<< <<<
Dry air filter cartridge
3-14/21 R N <<< R <<< <<< <<<
Radiator core
3-14 N N <<< <<< <<< <<< <<<
Fuel filter
3-18 N N <<< <<< <<< <<<
Alternator/fan/crankshaft belt tension
3-18 A C/A <<< <<< <<< <<<
I.C. engine oil **
3-20 V V <<< <<< <<<
I.C. engine oil filter **
3-20 R R <<< <<< <<<
Fuel filter cartridge
3-21 R R <<< <<< <<<
Fuel pre-filter
3-22 R R <<< <<< <<<
Alternator/fan/crankshaft belt
3-22 R R <<< <<< <<<
Fuel tank
3-24 N <<< <<<
Fuel tank breather
3-24 R <<< <<<
Safety dry air filter cartridge
3-24 R <<< <<<
I.C. engine silent blocks
C* <<< <<<
I.C. engine rates
C* <<< <<<
Valves clearances
C* C* <<< <<<
Cooling liquid
3-28 V <<<
Injection pump
C* <<<
Injectors
C* <<<
Radiator
C* <<<
Water pump and the thermostat
C* <<<
Alternator and the starter motor
C* <<<
Turbocompressor
C* <<<
Fuel circuit
3-30 P
TRANSMISSION
Front wheels reducers oil level
3-14 C C <<< <<< <<< <<< <<<
Front wheels reducers oil
3-29 V V <<<
Hydrostatic transmission circuit pressures
C* <<<
Governing start of the hydrostatic transmission
C* <<<
Working order of the hydraulic valves for the transmission
cut-off and accelerator
C* <<<
Wearing of brake discs
C*
TYRES
Tyre pressure
3-13 C C <<< <<< <<< <<< <<< <<<
Wheel nut torque
3-13 C C <<< <<< <<< <<< <<< <<<
Condition of wheels and tyres
C* <<< <<<
Wheel
3-31 R
MAST
Tension and alignment of the mast lifting chains
3-15 C/A C/A <<< <<< <<< <<< <<<
Mast
3-15 G G <<< <<< <<< <<< <<<
Mast lifting chains
3-23 N/C/G N/C/G <<< C* <<<
Condition of mast unit
C* <<<
Chain rollers
C* <<<
Mast guide rollers
C* <<<
Mast bearing rollers
C* <<<
Thickness of the mast wearing plates
C* <<<
HYDRAULIC
Hydraulic oil level
3-16 C C <<< <<< <<< <<< <<<
Hydraulic return oil filter cartridge
3-23 R R <<< <<< <<<
Hydraulic oil
3-25 V <<< <<<
Suction strainer for hydraulic oil tank
3-25 N <<< <<<
Filter cap for hydraulic oil tank
3-25 R <<< <<<
Speeds of hydraulic movements
C* <<< <<<
Hydraulic pump tubular filter
N* <<< <<<
Condition of hoses and flexible pipes
C* <<< <<<
Condition of cylinders (leakage, shafts)
C* <<< <<<
Hydraulic circuit pressures
C* <<<
Hydraulic circuit outputs
C* <<<
Hydraulic oil tank
N* <<<
