2-37
D - DISABLING “AGGRAVATING” HYDRAULIC MOVEMENT CUT-OFF
Authorization of this function can be configured from the OPT menu in the menu screen.
In certain cases, in order to get out of a difficult situation, the operator can bypass this
safety system. Button D temporarily disables the cutting-off of “AGGRAVATING” hydraulic
movements.
- Hold down button D, lamp D1 will light (60 second time delay), and simultaneously perform
the necessary ”AGGRAVATING” hydraulic movement with extreme care.
Remain very vigilant during this operation. The only information available to the operator is the lift truck’s
dynamic stability.
E - TESTING OF THE LONGITUDINAL STABILITY LIMITER AND WARNING DEVICE
- Short press the button
to verify at any time that the longitudinal stability alarm
is working.
• Correct operation: All the LEDs A1 to A8 light for two seconds and an audible
beep is sounded.
NOTE: This test does not check the proper adjustment of the longitudinal stability limiter that
must be inspected daily or after every 10 hours of service (see: 3 - MAINTENANCE:
A - DAILY OR EVERY 10 HOURS SERVICE).
F - STRAIN GAUGE
Disassembly or calibration of the strain gauge is prohibited, this must only be done by specially trained
personnel, consult your dealer.
F
D
A8
A7
A6
A5
A4
A3
A2
A1
D1
