HYDRAULIC CIRCUIT
- Type of pump
. Capacity
. Max. rating capacity unladen
. Flow rate at 2300 rpm
. Flow rate at 1600 rpm
- Pressure
. Lifting, tilting, telescoping, attachment circuit
. Steering circuit
- Filtration
. Return
. Suction
SPECIFICATIONS
- Level of sound pressure in the driver's cab LpA
(according to standard prEN 12053: 1995)
- Level of sound power in the LwA environment
(according to directive 2000/14/EC modified by directive 2005/88/EC)
- Average weighted acceleration on driver's body
(according to standard NF EN 13059)
- The average weighted acceleration trannsmitted to the driver's
hand/arm system
(in accordance with ISO 5349-2)
is less than 2.5 m/s2
- Speed of movement of lift truck in standard configuration on horizontal
ground (except particular conditions)
. Forward unladen
. Reverse unladen
- Standard lift height
- Rated capacity with standard attachment
- Load center
- Weight of forks (each)
- Lifting motions (jib retracted)
. Unladen lifting
. Laden lifting
. Unladen lowering
. Laden lowering
- Telescoping motions (lifting jib)
. Unladen extending
. Laden extending
. Unladen retracting
. Laden retracting
- Reverse tilt time unladen
- Forward tilt time unladen
- Lift truck weight with standard attachment
. Unladen
. Rated load
- Axle weight with attached equipment (transport position)
. Front unladen
rated load
. Rear unladen
rated load
- Tensible strain at coupling hook
. Unladen
. Rated load
- Break out force with bucket
(according to standard ISO 8313)
Gear pump with flow divider
43,8 cm3
105 L/mn
101 L/mn
70 L/mn
240 Bar
140 Bar
15 µm
125 µm
81 dB
105 dB
m/s2
27,3 km/h
27,3 km/h
6900 mm
3200 kg
24 in.
68 kg
6,7 s 40,4 m/mn
7,3 s 37,0 m/mn
5,0 s 54,1 m/mn
4,7 s 57,5 m/mn
6,3 s 25,7 m/mn
6,8 s 23,8 m/mn
3,3 s 49,1 m/mn
3,0 s 54,0 m/mn
2,8 s 44,9 °/s
2,3 s 54,6 °/s
7250 kg
10450 kg
3060 kg
8785 kg
4190 kg
1665 kg
5700 daN
8400 daN
7400 daN
2 - 9
