16 Part Number 000015432 4/18
Ice Machine Clearance Requirements
CNF201 - CNF202 Self-Contained Air-Cooled
Top 24" (61.0 cm)
Sides 8" (20.3 cm)
Back 5" (12.7 cm)
Ice Machine Heat of Rejection
Series Ice Machine Heat of Rejection*
Air Conditioning
CNF201 - CNF202 2,300
* BTU/Hour. Because the heat of rejection varies during the ice
making cycle, the figure shown is an average.
Ice machines, like other refrigeration equipment, reject
heat through the condenser. It is helpful to know the
amount of heat rejected by the ice machine when sizing air
conditioning equipment where self-contained air-cooled
ice machines are installed.
