Manitowoc IDF1400C Technician's Handbook

Part Number: 000015431 Rev01 5/19 189
Diagrams
Wiring Diagrams
The following pages contain electrical wiring diagrams. Be
sure you are referring to the correct diagram for the ice
machine you are servicing.
n
Warning
Always disconnect power before working on electrical
circuitry.
Some components are wired differently on energy efficient
machines. Please verify your model number (“CVD
Condensing Units” on page 20) to reference the correct
diagrams.
WIRING DIAGRAM LEGEND
The following symbols are used on all of the wiring
diagrams:
Equipment Ground
( ) Wire Number Designation
(The number is marked at each end of the wire)
—>>— Multi-Pin Connection
—> (Electrical Box Side)
>— (Compressor Compartment Side)
Male/Female Disconnect
Crimp Connector
