Installation Section 2
Water Supply and Drain Line Sizing/Connections
Location
Water
Temperature
Water Pressure
Ice Machine
Fitting
Tubing Size up
to Ice Machine
Fitting
Ice Making
Water Inlet
40°F (4.4°C) Min.
90°F (32°C) Max.
20 psi (140 kPa)
Min.
80 psi (550 kPa)
Max.
3/8" Female Pipe
Thread
3/8" (10 mm)
minimum inside
diameter
Ice Making
Water Drain
— —
1/2" Female Pipe
Thread
1/2" (13 mm)
minimum inside
diameter
Condenser Water
Inlet
40°F (4.4°C) Min.
90°F (32°C) Max.
20 psi (140 kPa)
Min.
276 psi
(1900 kPa) Max.
I0300 - I1200 = 3/8"
Female Pipe Thread
I1500 - I1800 = 1/2"
Female Pipe Thread
Condenser Water
Drain
— —
1/2" Female Pipe
Thread
1/2" (13 mm)
minimum inside
diameter
Bin Drain — —
3/4" Female Pipe
Thread
3/4" (19 mm)
minimum inside
diameter
Large Capacity
Bin Drain
1" Female Pipe
Thread
1" (25 mm)
minimum inside
diameter
Min. = Minimum, Max. = Maximum
Water Connections
• Local water conditions may require
treatment of the water to inhibit scale
formation, filter sediment, and remove
chlorine odor and taste.
• Connect ice making water inlet to
potable water only.
• Install a water shut-off valve for potable
water and water cooled condenser lines.
• Do not connect the ice machine to a hot
water supply. Verify hot water restrictors
installed on other equipment are
functioning correctly. (Check valves on
sink, faucets, dishwashers, etc.)
• Install a water regulating valve if water
pressure exceeds the maximum valve
rating.
• Insulate water and drain lines to prevent
condensation.
