Installation Instructions Section 2
12
Part Number 000007345 2/14
Maximum Breaker Size & Minimum Circuit Amperage Chart
Due to continuous improvements, this information is for reference only.
Please refer to the ice machine serial number tag to verify electrical data.
Serial tag information overrides information listed on this page.
Ice
Machine
Voltage/ Phase/
Cycle
Air-Cooled Water Cooled Remote
Maximum
Fuse/Circuit
Breaker
Minimum
Circuit Amps
Maximum
Fuse/Circuit
Breaker
Minimum
Circuit Amps
Maximum
Fuse/Circuit
Breaker
Minimum
Circuit Amps
I0300
115/1/60 15 10.8 15 10.0 N/A N/A
230/1/50 15 6.1 15 5.6 N/A N/A
230/1/60 15 6.1 15 5.7 N/A N/A
I0306
115/1/60 15 10.8 15 10.0 N/A N/A
230/1/50 15 6.1* 15 5.6* N/A N/A
230/1/60 15 6.1* 15 5.7* N/A N/A
I0320
115/1/60 15 11.5 15 10.7 N/A N/A
208-230/1/60 15 6.0 15 5.6 N/A N/A
230/1/50 15 6.0 15 5.6 N/A N/A
I0450
115/1/60 20 13.2 20 12.5 N/A N/A
208-230/1/60 15 6.6 15 6.2 N/A N/A
230/1/50 15 7.1 15 6.8 N/A N/A
I0456
115/1/60 20 13.2* 20 12.5* N/A N/A
208-230/1/60 15 6.6* 15 6.2* N/A N/A
230/1/50 15 7.1* 15 6.8* N/A N/A
I0500
115/1/60 20 14.2 20 13.5 25 20.0
208-230/1/60 15 6.1 15 5.7 N/A N/A
230/1/50 15 7.1 15 6.8 15 6.7
I0520
115/1/60 20 14.4 20 13.5 N/A N/A
208-230/1/60 15 6.1 15 5.7 N/A N/A
230/1/50 15 7.1 15 6.8 N/A N/A
I0600
208-230/1/60 15 10.2 15 9.7 15 10.7
230/1/50 15 6.7 15 6.1 15 7.1
I0606
208-230/1/60 15 11.1 15 10.7 15 11.7
230/1/50 15 6.7 15 6.1 15 7.1
I0850
208-230/1/60 20 11.9 20 10.9 20 11.9
208-230/3/60 15 9.2 15 8.2 15 9.2
230/1/50 20 10.8 20 9.4 15 10.4
I0906
208-230/1/60 20 12.2 20 11.2 20 12.2
208-230/3/60 15 9.7 15 8.7 15 9.7
230/1/50 20 12.2 20 11.2 15 12.2
I1000
208-230/1/60
20 13.5 15 9.7 15 10.7
208-230/3/60 15 9.5 15 8.5 15 9.5
230/1/50
20 13.7 20 12.3 20 12.3
380-460/3/50-60
N/A N/A 15 4.5 N/A N/A
I1100
208-230/1/60
20 13.5* 15 9.7* 15 10.7*
208-230/3/60 15 9.5* 15 8.5* 15 9.5*
230/1/50
20 13.7* 20 12.3* 20 12.3*
