CONTROLS AND OPERATING PROCEDURES OPERATOR MANUAL NBT50
3-6 Published 03-23-2018 Control # 243-14
FIGURE 3-3
6
5
2
1
4
7448-1
7459-16
5
5
5
7
7
7448-4
7459-1
3
3
3
8
Item Description Item Description
1 Outrigger Midspan Selector Pin 5 Outrigger Stabilizer & Jack Cylinder
2 Outrigger Beam Assy Long 6 Ground Station Outrigger Controls
3 Outrigger Beam Assy Short 7 Outrigger Extend/Retract Cylinder
4 Level Indicator (inside cab) 8 Level Indicator
