Manitowoc National Crane NBT50 Series - Page 94

SET-UP OPERATOR MANUAL NBT50
4-6 Published 03-23-2018 Control # 243-14
1Stow Pin
2 Jib Stowage Bracket
3 Hook Bracket
4 Boom
5 Jib Swing Pin
6 Right Side Attachment Pins
7 Left Side Attachment Pins
8Jib
9 Jib Retaining Pin
10 Alignment Jack
FIGURE 4-3
1
2
3
4
5
6
7
8
9
10
