CONTROLS AND OPERATING PROCEDURES OPERATOR MANUAL NBT60L
3-38 Published 09-06-2019 Control # 691-01
2. In the cab, remove the safety pin (1, Figure 3-30) and
bushing (2) from the anemometer stowage bracket (3).
3. Install the anemometer mast (4) on the stowage bracket
rod keeper (5).
4. Install the bushing (2) over the mast (4) and rod keeper
(5). Align the bushing and keeper holes so the safety pin
can be installed.
5. Install the safety clip in the bushing (2) and keeper holes
(5) to secure the anemometer mast (4). Secure the pin
(1) with the safety clip.
FIGURE 3-30
3
4
5
2
1
9699
9700
