42 Part Number 80-01111-9 7/10
WATER
PUMP
EVAPORATOR
WATER
SHUTTER
ASSEMBLY
NOTE:
EVAPORATOR
REMOVED
FOR CLARITY
EVAPORATOR
BUCKET
CONTROL
BOARD
WATER
SHUTTERS
SPRAY
NOZZLES
SPRAY
BAR
WATER
SUPPLY
LINE
