Part No. 80-1100-3 2-1

Section 2

Installation Instructions

General

Refer to Installation Manual for complete installation

guidelines.

Ice Machine Dimensions

Q320/Q370/Q420 ICE MACHINES

Important

Failure to follow these installation guidelines may

affect warranty coverage.

SV1602 SV1611

WATER COOLED AIR COOLED

Ice Machine Dimension H

Q320 21.5 in (54.6 cm)

Q370 21.5 in (54.6 cm)

Q420 26.5 in (67.3 cm)
