–66–
Q0600C/Q0800C/Q1000C
SV1605A
FLOW CLAMP USED
ON REGULAR SIZE
CUBE ONLY
DISTRIBUTION
TUBE
ICE THICKNESS
PROBE
EVAPORATOR
WATER CURTAIN
WATER TROUGH
WATER PUMP
ICE/OFF/CLEAN
SWITCH
