148 Part Number: 000015431 Rev01 5/19
THERMISTORS
FUNCTION
Thermistor resistance values change with temperature.
The value supplied to the control board is used to identify
temperature at the thermistor location.
SPECIFICATIONS
Temperature of Thermistor Resistance
°C °F K Ohms (x 1000)
-30° - -20° -22° - -4° 820.85 - 466.35
-20° - -10° -4° - 14° 466.35 - 269.05
-10° - 0° 14° - 32° 269.05 - 160.70
0° - 10° 32° - 50° 160.70 - 98.930
10° - 20° 50° - 68° 98.930 - 62.015
20° - 30° 68° - 86° 62.015 - 39.695
30° - 40° 86° - 104° 39.695 - 25.070
40° - 50° 104° - 122° 25.070 - 17.481
50° - 60° 122° - 140° 17.481 - 11.860
60° - 70° 140° - 158° 11.860 - 8.1900
70° - 80° 158° - 176° 8.1900 - 5.7530
80° - 90° 176° - 194° 5.7530 - 4.1015
90° - 100° 194° - 212° 4.1015 - 2.9735
100° - 110° 212° -230° 2.9735 - 2.1885
110° - 120° 230° - 248° 2.1885 - 1.6290
120° - 130° 248° - 266° 1.6290 - 1.2245
130° - 140° 266° - 284° 1.2245 - 0.9319
140° - 150° 284° - 302° 0.9319 - 0.7183
150° - 160° 302° - 320° 0.7183 - 0.5624
160° - 170° 320° - 338° 0.5624 - 0.4448
170° - 180° 338° - 356° 0.4448 - 0.3530
180° - 190° 356° - 374° 0.3530 - 0.2831
190° - 200° 374° - 392° 0.2831 - 0.2273
