–52–
FLOAT VALVE
SU1000C/Q1400C
1. Turn off the water supply to the ice machine at the
water service valve.
2. Turn the splash shield counterclockwise one or two
turns.
3. Pull the float valve forward and off the mounting
bracket.
4. Disconnect the water inlet tube from the float valve
at the compression fitting.
5. Remove the filter screen and cap for cleaning.
