Part Number 80-1479-3 7/10 267
Diagrams
Wiring Diagrams
The following pages contain electrical wiring diagrams.
Be sure you are referring to the correct diagram for the
ice machine you are servicing.
Some components are wired differently on energy
efficient machines. Please verify your serial number
(page 12) to reference the correct diagrams.
WIRING DIAGRAM LEGEND
The following symbols are used on all of the wiring
diagrams:
* Internal Compressor Overload
(Some models have external
compressor overloads)
** Fan Motor Run Capacitor
(Some models do not incorporate fan
motor run capacitor)
( ) Wire Number Designation
(The number is marked at each end of
the wire)
—>>— Multi-Pin Connection
(Electrical Box Side) —>>—
(Compressor Compartment Side)
To Next Page
