Part Number 000001590 Rev03 11/19 17
Component Identification
Section 3
Operation
Water
Inlet
Drain
Optional
Drain
Pump
Electric
Power
Cord
Refrigeration
Compressor
Water
Pump
Note:
Evaporator
Removed
For Clarity
Water
Shutters
Spray
Nozzles
Spray
Bar
Water
Supply
Line
Evaporator
Bucket
Control
Board
Water
Pump
Evaporator
Water
Shutter
Assembly
Bin
thermostat
Located
Behind
Grill
Bin
Water
Trough
Water
Shutters
Bin
Light
Control
Panel
Evaporator
Compartment
Optional
Water
Filter
Grill
Optional
Legs
