Installation Instructions Section 2
8
Part Number 040001361 05/10
Step-by-Step Installation Procedure
1. Prepare the site by following the instructions under
Electrical Service and Water Supply and Drain
Requirements.
2. Remove ice machine from carton.
3. Inspect for damage.
4. Remove literature/warranty packet and drain hose
from inside the ice machine.
5. Adjust leg levelers (or install optional legs).
6. Reverse door if desired. See Reversing Door Swing
on
page 9.
7. For a gravity drain, install drain hose to drain on back
of ice machine and route to open site drain. For
optional drain pump method, see Drain Pump Option
on
page 9. Refer to Water Supply and Drain
Requirements on page 7.
8.
Use compression fitting to connect the Water Inlet
on back of ice machine to the prepared 1/4" ID cold
water line. Refer to Water Supply and Drain
Requirements on
page 7.
9. Open the shut-off valve on the water line.
10. Connect electrical plug to grounded (three-prong),
polarized outlet. See Electrical Service on
page 6.
11. Place ice machine back in position and check
leveling again. Make any necessary adjustments.
12. Prepare sanitizer solution and sanitize the ice
machine according to In Place Cleaning/Sanitizing
Procedure steps 5 and 6.
13. Put one gallon of cold water into a container that will
easily pour under the lifted water shutters. Open
shutters and add one gallon of cold water.
14. Press Power button.
15. At initial start-up, ice machine will need
approximately 30 minutes to freeze ice and up to
5
minutes to harvest the ice.
Check all visible connections for water leakage.
The ice machine must be grounded in accordance
with national and local electrical codes. Do not use
an extension cord or adapter.
Improper water supply and drain connections can
result in personal injury and substantial property
damage. These connections are the responsibility
of the owner/operator.
