Manitowoc SMS050A002 User Manual

72 Part Number 80-01111-9 7/10
SUMP DRAIN OVERFLOW TUBE
1. Remove clamp.
2. Pull down to remove overflow tube and tubing as
an assembly. The sump trough water will drain
into the bin.
3. Remove overflow tube from vinyl tubing by
pulling.
REMOVE CLAMP
AND
PULL DOWN

Manitowoc SMS050A002 Specifications

General

Brand	Manitowoc
Model	SMS050A002
Category	Ice Maker
Language	English
