Manitowoc UDF0240A

Part Number 000014797 Rev02 05/18 127
Operational Analysis  2  
Safety Limits
Refer to “Analyzing Safety
Limits” to eliminate all non-
refrigeration problems.
Stops on safety limit:
1 or 2
Stops on safety limit:
1
Stops on safety limit:
1 or 2
Stops on safety limit:
1
Ice Formation Pattern Ice formation is extremely
thin on outlet of
evaporator
-or-
No ice formation on entire
evaporator
Ice formation is extremely
thin on outlet of
evaporator
-or-
No ice formation on entire
evaporator
Ice formation is normal
-or-
Ice formation is extremely
thin on the bottom of
evaporator
-or-
No ice formation on
evaporator
Ice formation is normal
-or-
No ice formation on entire
evaporator
Safety Limits
Refer to “Analyzing Safety
Limits” to eliminate all non-
refrigeration problems.
Stops on safety limit:
1 or 2
Stops on safety limit:
1
Stops on safety limit:
1 or 2
Stops on safety limit:
1
