SPECIFICATIONS
- MANLEY input & output transformers with nickel laminations in mu-metal cases with at fre-
quency response from 20Hz-25kHz
- BALANCED INPUTS & OUTPUTS (600 Ohms)
- Fully differential ALL-TUBE circuitry using one each 5670, 5751, 7044 or 5687, & 12AL5 per
channel (T-BAR mod replaced 5670’s with 2 pairs of 6BA6’s)
- Independently regulated B+ and Heater supplies
- Hard-wire BYPASS switch
- INPUT LEVEL switch: -8, -4, -2, -1, 0, +1, +2, +4, +8dB
- RECOVERY 5 steps: 0.2s, 0.4s, 0.6s, 4sec., 8sec.
- Variable ATTACK: 25msec-70msec
- Continuously variable THRESHOLD
- LIMIT (4:1 to 20:1) or COMPRESS (1.5 to 1)
- HP Side Chain Filter: 6dB per octave, approximately -3dB at 100Hz.
- Large ILLUMINATED Sifam METERS (older units before serial number MSLC61642 shipped
before 12/2003 use: 26V 1.2W FESTOON LAMPS; Manley’s Part Number: VAR016B) Order
spare bulbs using our parts order form. (newest units after serial number MSLC61642 shipped
after 12/2003 use white LED lighting)
- STEREO LINK SWITCH
Several units can be linked for Surround (custom order )
- Maximum gain: 35dB
- Max. output: +30dBu (26Vrms) 26dB Headroom
- <0.1% THD @ 1kHz Noise oor: -85dB typical
- Power Consumption (120/240VAC): 80 watts
- Unit is factory set for 100V, 120V or 220-240VAC operation for original destination country’s
mains voltage.
- Operating Mains Voltage changeable with power transformer changeover switch and fuse value
change.
- Mains Voltage Frequency: 50~ 60Hz
- Dimensions: 19” x 3 1/2” x 10” (chassis occupies 2U). Power transformer protrudes 3.5” out the
back of the chassis.
- Shipping Weight: 23 lbs.
