Intended purpose
The mitre-cutting saw is used to saw wood or soft metals (AI, Zn, Ni,
Ms, Cu) using the corresponding blade. The device is specifically
designed for straight cuts at various mitre angles (see “Technical data”
for angle settings).
Scope of delivery
1 mitre-cutting saw
1 saw blade for metal
1 saw blade for wood
1 hex wrench
1 user manual
Tool breakdown view (Fig. 1)
29. Saw table
30. Base plate
31. Material holder
32. Angle scale
33. Turntable rail
34. Clamp bolts for limiting cutting
depth
35. Adjuster catch for angle setting
36. Wing nut for tightening saw
blade
37. Hand grip
38. Lengthwise stop
39. Guide cylinder
40. Saw blade
41. Guide bar
42. Guide slider
