Technical data
Cutting width: 170 mm (at 90°) / 129 mm (at 45°)
Max cutting height: 106 mm
Table length: 400 mm
Saw blade length: 550 mm
Angle settings 90°/0°, 75°/15°, 67,5°/22.5°, 60°/30°,
54°/36°, 45°
Weight 3.7 kg
Year built 2006
Wear gloves and, if applicable, dust mask while working!
Assembly (Fig. 6)
25. Loosen the fastening bolts (G) on the turntable bolt with the hex
wrench until the turntable bolt (H) can be withdrawn.
26. Position the turntable rail (5) to the saw table (1) from underneath,
aligning the bore holes on the rail and saw table for the turntable
bolt.
27. Insert the turntable bolt the whole way into the holes and secure by
turning in both holding bolts (G).
Do not tighten the holding bolts up, otherwise you will not be able
to turn the saw to adjust the angle.
28. Tighten the screws in the holes intended and the four bolts (I) on
the base plate (2).
29. Tighten the device feet provided with the fastening bolts (J) to the
base plate from underneath.
30. Position the slider (14) of the saw over the four guide bars (13).
31. Clamp the base plate (2) of the mitre-cutting saw between the
clamping jaws on the carpenter’s workbench or with screw clamps
onto any other work surface.
32. Turn the lengthwise stop (10) and work piece fastener (3) up to the
end of the threaded bar in the saw table either from the left or right,
and secure with the corresponding nuts.
