Operating Manual
PR-050823-0121 Version 161109 11 of 14
5.3 P
REPARATION FOR CONNECTION
Make sure the operating space is clear to avoid accidental contact with others and the
coupling interface is clean and dry. Use dry air or nitrogen to blow out the coupling
interface.
Before making the connection, make sure that there is no trapped liquid or excessive pressure
behind the tank unit when connecting.
If required by the application, be sure to connect the ground cable.
Take off the protection cap from the tank unit and the plug from the hose unit.
Blow out both couplings with dry compressed air or nitrogen to clear off any moisture or snow.
Do not connect!
Snow shall be blown
off!
OK to connect
Lift the hose unit and hose into position to start the connection. Take care to
support the hose end assembly so as to fit the hose unit to the tank unit in the
correct orientation.
It is important to ensure the hose unit is not supporting the full weight of the hose
assembly during the connection process. Once connected, the hose unit is
secure to the tank unit and able to accommodate all reasonable axial strain.
When correctly supported, the hose unit should slide easily over the tank unit.
The three rollers on the hose unit engage in the three slots on the tank unit in
any one of three positions at 120 degree centre.
