MA409
4
EN
SPECIFICATIONS OVERALL:
Frequency Range FM121.7-128.8MHz
Frequency Response 100Hz-10000Hz(±3dB)
Audio Distortion Less than 1%
Dynamic Range 80dB
S/N Ratio Better than 80dB
Operating Temperature 0C-45C
Service areas 10m
TRANSMTTER MICROPHONE:
Type of Emission FM
RF output power 8mw(50mw maximum)
Frequency Deviation 75KHz
Battery 9V storey battery
RECEIVER
Type of reception FM
Reception Mode super heterodyne space diversity
Audio Output level >25mV
Reception Sensitivity 600W(unbalanced)
Power 30dB/µV AC220V/50Hz AC110V/60Hz
Dimensions 420(W)x180(D)x50(H)mm
