With the television in the lowered position, remove the
Safety Nut {21} and Safety Bolt {20} from the Lifting
Mechanism {35}.
KEEP THIS BOLT AND NUT in a safe place for use in the
future. They are needed to remove the television or
change the Gas Springs. Recommendation: Tape them to
the inside of the Wall Cover {29}.
41
MantelMount MM700 PAGE 17
Never release the handle before it is fully upright.
MantelMount is strongest in the top position, and
allowing it to slam closed can damage televisions.
Always control the lifting process.
!
CAUTION:
Never allow children to play around or operate
MantelMount. Property damage or personal injury
can occur.
!
CAUTION:
Install the Wall Covers using the included adhesive Velcro
strips as shown below. Apply Loop {26} pieces to the Wall
Frame, and the Hook {25} pieces to the Wall Covers.
40
Loop
Hook
To Next Page
