3
Parts For The Support Frame
Parts For The Support Frame
PART QUANTITY
ITEM NO.
DESCRIPTION NEEDED
1 Lower Support 2
2 Support Spacer 4
3 Drive Handle 1
4 Upper Support 2
(with axle rod carriers)
5 Axle Rods 2
6 Drive Wheels 4
7
1
/
2
"x 2" Bolt
8
8 Grip 1
9 Grip Cap 1
10 Spring Pin 4
11 #6
Screw
1
1
2
3
9
4
7
8
5
6
12
13
14
15
16
18
19
20
21
17
22
23
24
25
26
28
29
30
27
PART QUANTITY
ITEM NO.
DESCRIPTION NEEDED
12
Drum Segment A
1
13
Drum Segment B
2
14 Endcap 2
15
Door Frame Segment
1
16
Tie Rod,
1
/
4"x 36
3
/
4"
4
17
AeratorBase
(outside)
2
18
AeratorCap
(inside)
2
19 Latch Hook 2
20 Latch 2
21 Door 1
22
#10 Bolts
18
23
#10 Flat Washer
34
24
#10
Lock Washer
18
25
#10 Hex
Nut
18
26 Acorn Nut,
1
/
4
"
8
27
Bolt,
1
/
4
"x3
1
/
4
"
2
28 Wing Nut,
1
/
4
"
2
29
Shoulder Bolt
16
30 #10 Lock Nut 16
Parts For The Tumbler Drum
Parts For The Tumbler Drum
10
11
Note: The Tie Rods (Item 16) have been shipped inside the Support Spacers
(item 2). Be sure to remove them before assembling the frame.
ENLARGED VIEW
To Next Page
