Maplin A75TB - Technical Specifications; Product Technical Parameters

Technical Parameters
Produc
t model A75TB
Rated voltage
220 -240V
Rated frequency 50 Hz
Rated power Cooling:70W; Heating:2000W
Noise (strong mode)
≤64dB
Rated wind output 260m
3
/h
Rated evaporation 800mL/h
Energy efficiency ratio 7W/W
Dimensions
L/250mm×W/330mm×H/703.5mm
Net weight
10Kg
Package weight
12Kg
Standard IEC/EN Stardard
Wiring Diagram
Water Level Switch
High-water Level
Switch
Cold wind Switch
Hot wind Switch
