23
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
EXPLODED VIEW PART (MECHANISM)
1 08AW248010 08AW248010 PANEL CC4300/U1B ABS(AF303)BK/FRONT 3067210781020
2 08AW063010 08AW063010 COVER TRAY/ABS(AF303)BK 4317210351000
3 08AW158010 08AW158010 WINDOW DISPLAY/ACRYL WINE 5070210783000
4 08AW270020 08AW270020 BUTTON 6KEY-A/ABS(HF380) BK 5090211631000
5 08AW270030 08AW270030 BUTTON 6KEY-B/ABS(HF380) BK 5097211641000
6 08AW270010 08AW270010 BUTTON POWER/ABS(HF380) BK 5090211651000
7 08AW270040 08AW270040 BUTTON CC4300/U1B 7KEY/ABS(HF380) BK 5097211661000
8 168W251010 168W251010 BADGE BADGE(MARANTZ) 563704097802A
9 nsp nsp INDICATOR GUIDE LED AX9030 5160041003010
10 08AW154010 08AW154010 KNOB VOLUME/ABS(HF380) 5080210541000
11 nsp nsp CHASSIS MAIN 3200210206100Z
12 /A nsp nsp CHASSIS REAR PANEL BACK CHASSIS CC4300/A1B 3207042616250Z
12 /F nsp nsp CHASSIS REAR PANEL BACK CHASSIS CC4300/F1B 3207042616240Z
12 /N nsp nsp CHASSIS REAR PANEL BACK CHASSIS CC4300/N1B 3207042616230Z
12 /U nsp nsp CHASSIS REAR PANEL BACK CHASSIS CC4300/U1B 3207042616220Z
13 nsp nsp CABINET (TOP COVER) BLACK 3000044516000Z
14 322W057010 322W057010 FOOT FOOT (GOLD AM4736-615AL) HOT STAMPING 4007040241030
15 nsp nsp SUPPORTER HCD60M ABS/PCB 4070000980000
16 nsp nsp CUSHION D-XW33(J) EVA 30x15x12t /PCB 4050210415000
17 nsp nsp GUIDE CC4300/U1B MECHA/ABS(AF380)BK 4350210021000
18 nsp nsp BRACKET CDC5090R(DOM) ET.HD0.3t(A4)/VFD 4010210296000
19 nsp nsp BRACKET CC4300/U1B FRAME/FRONT 4010211256000
20 nsp nsp CUSHION AVC1500(N) RUBBER
BK(PI18xPI10x3.5T)/RUBBER
4050210165000
21 nsp nsp CUSHION CC4300/U1B TOP COVER/CR60 4050210665000
A *RB000020R *RB000020R VR ROTARY 9MM RK0971220-2KBx2-M(ALPS) C451122200100
B *SP001140R *SP001140R SW TACT SKHV10920A 5MM/260G-REEL G180000270010
C *HQ300560R *HQ300560R DISPLAY FLT HNA-09SM13 49PIN(ANGLE) K530001270030
D nsp nsp JACK D6.5 HTJ064-11D(G)/WTJ06411D(G)WELLCO G402040161330
E /F nsp 323W259020 STOPPER CORD HOLDER DACH-2 4380040172010
E /U/N/A 323W259030 323W259030 STOPPER CORD HOLDER DACH-1 4380040162010
F /U nsp *YC000690R MAINS CORD ASSY SPT2 10A/125V L06802003008C
F /F nsp *YC000700R MAINS CORD ASSY KP235 12A/125V L068000000080
G *HW100580R *HW100580R MODULE REMOCON NJL64H360A 36kHz E940643600000
H *YJ002490R *YJ002490R TER RCA 2PIN JK020130LN(GND PLATE&PIN)/ORINGE G601020130050
I *YT002800R *YT002800R TER RCA 2PIN JK020130PN(GND PLATE&PIN) G601020130020
J *YT002670R *YT002670R TER RCA 1PIN JE010003PN(GND) BLACK G600010003050
K *YT002580R *YT002580R MODULE GP1FA502TZ /OPTICAL TRANSMIT 96kHz E100150200030
L *SS000700R *SS000700R SW SLIDE SSAF112NA011 G060112011010
M /F nsp *TS001670R POWER TRANS CC4300(F1B) 100V/50Hz 48x25 8200480250090
M /N/A *TS001660R *TS001660R POWER TRANS CC4300(N1B) 230V/50Hz 48x25 8200480250100
M /U nsp *TS001650R POWER TRANS CC4300(U1B) 120V/60Hz 48x25 8200480250080
N *YU001020R *YU001020R CABLE FLAT CARD 1.25x35*320xD(5/5/10)x(0.1x0.8) L301321350010
O *YU001010R *YU001010R CABLE FLAT CARD 1.0x16x250xC(5/5/10)x(0.035x0.65) L301251160010
P nsp nsp CN WIRE 120MM/6P GIL-S-06=PHR-06 WH20080#28 L000121060020
Q nsp nsp MECHA ASSY ICM04B MECHA ASSY (LOADER AND
TRAVERSE)
8038041479010Z
R /N *YC000680R *YC000680R MAINS CORD ASSY(/N) HITACHI EHD477A L06804001102C
S nsp nsp FASTENER BUTTON SUPPORT DABS-35R 4420210023010
T nsp nsp CN.WAFER INTERFACE 9P FEMAIL D-SUB (SH232CF) L103090090020
U /A nsp *YC000670R MAINS CORD ASSY 7.5A/250V 2M L06804023001C
S1 nsp nsp SCREW TAP TITE +2S 3x8 B-TYPE ZNY/BH B020030081B10
S2 nsp nsp SCREW TAP TITE AVR3300(E3)(DENON) +2S 3x10 B-TYPE(DOT)
BK/BH
B020030103B11
S3 nsp nsp SCREW TAP TITE +3S 4x8 BK/BH B020940083B10
S4 nsp nsp SCREW TAP TITE +2S 3x17 B-TYPE ZNY/BH B020030171B10
