NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
S5 nsp nsp SCREW +2S 3x8 ZnY WASHER PI12 1500001456010
S6 nsp nsp SCREW TAP TITE +3S 4x8 S-TYPE ZNY/BH B020740081B10
S7 nsp nsp SUPPORT STUD NO4-4OUNC H=5.0 4120100177010
S8 nsp nsp SCREW TAP TITE +2S 3x8 B-TYPE BK/BH B020030083B10
M01 nsp nsp BODY MECHA 3410041401010
M02 08AW163010 08AW163010 TRAY LOADING 4600040241010
M03 08AW163020 08AW163020 ROULETTE TRAY 2720040061010
M04 08AW401020 08AW401020 BASE PU DRIVE 3400041391010
M05 08AW058020 08AW058020 GEAR CENTER (A) 2470040291010
M06 08AW058010 08AW058010 GEAR CENTER (B) 2470040211010
M07 08AW058030 08AW058030 GEAR TRAY 2470040683010
M08 08AW262010 08AW262010 GEAR PULLEY 2470040341010
M09 08AW360010 08AW360010 SLIDER FUNCTION 2640040031010
M10 08AW354010 08AW354010 ARM GEAR 2540041133010
M11 08AW262020 08AW262020 PULLEY MOTOR 2500000310000
M12 08AW116010 08AW116010 PLATE PRESSURE 4470043826010
M13 08AW264010 08AW264010 BELT LOADING 2490040595010
M14 08AW058050 08AW058050 GEAR W-WHEEL 2530041563010
M15 08AW058040 08AW058040 GEAR WORM 2470040693010
M16 08AW358010 08AW358010 ROLLER TRAY 2520040473010
M17 nsp nsp POLY WASHER 8x14x0.5t 1537040366010
M18 nsp nsp SPRING ROULETTE 3720044506010
M19 nsp nsp PLATE CLAMPER 4470004050000
M20 nsp nsp MAGNET 7800GZ3400L10
M21 08AW005010 08AW005010 CLAMP BASE 4330020041010
M22 nsp nsp CON'T L=70 MOTOR L000079550000
M23 nsp nsp CON'T L=350 LOADING L000079520000
M24 *YU001040R *YU001040R FLAT CABLE 25P(P=1L=230MM) L301700360010
M25 08AW056010 08AW056010 INSULATOR RED 1240020135020
M26 08AW056020 08AW056020 INSULATOR GREEN 1240020135010
M27 08AW051010 08AW051010 GUIDE TRAY 4350042061010
M28 nsp nsp PCB OF SENSOR 7020059830000
M29 nsp nsp HOUSING 6P 4428606965000
A 08AW304500 08AW304500 TRAVERSE(PICK UP UNIT KSN213CCM) 8030040622010
B *SM000400R *SM000400R SW LEVER SSCF21062A G140040220010
C *MM001240R *MM001240R MOTOR DC FF-130SH-14230 G700040400010
D *MM001250R *MM001250R MOTOR DC SM3220BT G700322000110
E *HW100610R *HW100610R PHOTO SENSOR SG-23F1 K611230000000
F *HW100620R *HW100620R PHOTO SENSOR ON2173-RS K611217300000
PACKING
/F nsp 08AW851110 USER GUIDE (/F) 5707047250070
/N/A 08AW851310 08AW851310 USER GUIDE (/N/A) 5707047250060
/U nsp 08AW851250 USER GUIDE (/U) 5707047250050
nsp ZK08AW0010 REMOTE CONTROLLER RC4300CC 8300430000010
NOT STANDARD SPEAR PARTS
08AW801010 08AW801010 PACKING CASE 6017040940150
08AW809010 08AW809010 CUSHION SNOW L/R 6230210444000
nsp nsp BATTERY DRY G670001R50010
/F nsp nsp POST CARD(JAPAN) 5777200120030
/F nsp nsp CARD
WARRANTY(JAPAN)
5777200120040
/N nsp nsp CARD IMPORTANT 5777200120050
/U nsp nsp CARD WARRANTY(USA) 5777200120010
/U nsp nsp CARD WARRANTY(CANADA) 5777200120020
