Marantz CD-73 - 5. VOLTAGE CONVERSION

1) CD OUT JACK
Use
the
accessory
RCA
pin
cord
to
conenct
this
jack
to
the
CD
or
AUX
jack
on
your
preamplifier
or
pre-main
amplifier.
@ REMOTE JACK
Connecting
this
jack
to
the
optional
infrared
remote
control
kit
enables
remote
control.
For
details,
see
the
instruction
booklet
on
the
infrared
remote
control
kit.
3) AC POWER CONNECTION
The correct voltage for operating your unit is written on the rear
panel. Be sure the POWER push-switch is out before plugging the
AC fine cord into an electrical outlet.
4} POWER SWITCH
Pushing this switch turns on the unit's power, and pushing it again
turns the power off.
5) POWER INDICATOR
Lights red when the power is on.
6 OPEN/CLOSE SWITCH
Pushing this switch (so that it is out) caused the drawer containing
the platter to open automatically; pushing it again (so that it is in)
causes the drawer to automatically close.
Discs can be loaded when the drawer is open.
@ vrawer
This is where discs are loaded for playing. This drawer pulls out (to
conserve space), and opening and closing is driven by a motor.
@ oreration Buttons
Reverse button (REV):
Pressing this button during playback causes the laser pickup to move
toward the beginning of the disc from the selection which is current-
ly being played.
Fast forward button (FF):
Pressing this button during playback causes the laser pickup to move
toward the end of the disc from the selection which is currently
being played.
Play button (NEXT PROGRAM/PLAY):
Press this button to start playback. When this button is pressed
while playback is in progress, the laser pickup moves to the next
selection on the disc.
Pause button (PAUSE):
When
this
button
is
pressed
during
playback,
the
player
stops
at
the point at which the button is pressed. Pressing the button again
cause playback to resume at the point at which it was interrupted.
© stanpey invicaTor
Lights to indicate that the drawer is properly closed. Playback is
not possible except when this indicator is Jit.
Q) Laser invicator
Lights to indicate that the laser is operating and that playback is
in progress.
@ Pause invicator
Lights during pause.
® STOP/ALL CANCEL BUTTON
This button is used to stop playback or to clear the program.
® SELECT BUTTON
This button is used to specify the desired selection number.
@ Preset BuTTON
This button is used to store the desired selection number in memo-
ry. ;
@® ReEPeat BUTTON
Pressing this button causes all programmed selections to be re-
peated; pressing it again stops repetition.
@ cance sutton
This button is used to delete the selection number specified by the
SELECT button from memory.
® LOADING INDICATORS
The indicator corresponding to the selection which is being played
lights. The applicable indicator flashes during programming, and
moves one-step to the right each time the SELECT button is
pressed; the selection number corresponding to the indicator flash-
ing is stored in memory when the PRESET button is pressed.
@ Procram invicaTors
Indicators correspond to selections to be played light and those
corresponding to the selections which have been played go out. All
indicators remain when the repeat function is on.
@ REPEAT INDICATOR
Lights when the repeat function is activated by the REPEAT
button.
@) oveR FL INDICATOR
Lights momentarily when an attempt is made to store a selection
number in memory when the memory is already full. {The maxi-
mum number of selections which can be stored in memory is 15.)
@) disc cLAMPER
The disc clamper is automatically raised when the drawer is opened
for loading; it is automatically lowered to hold the dise in place
when the drawer is closed for playback.
@ PLATTER
The platter uses a high-precision, automatic centering mechanism
to correctly position the disc.
@® Laser Pickup
Reads music data recorded on the disc.
Note: Never touch the jens or pickup.
