POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
HF AMP CIRCUIT BOARD
1500 4822 267 10871 CONN.17POL. FEM.
1501 4822 267 51453 CONN. 39-51-3123 (12P)
2500 5322 122 31865 1.5NF 10% X7R 63V
2501 5322 116 80853 560pF 5% NP0 63V
2502 5322 122 31647 1NF 10% X7R 63V
2503 4822 126 13751 47NF 10% X7R 63V
2504 4822 126 13751 47NF 10% X7R 63V
2505 4822 124 40433 47 F 20% 25V
2506 4822 124 12435 0.47UF 20% 50V
2507 4822 124 40433 47 F 20% 25V
2508 4822 126 13751 47NF 10% X7R 63V
3500 4822 117 10837 100K 1% 0.1W
3501 4822 117 10833 10K 1% 0.1W
3503 4822 051 20229 22R00 5% 0.1W
3504 4822 051 20223 22K00 5% 0.1W
4500 4822 051 20008 0R00 JUMP. (0805)
7404 5322 209 11517 PC74HCU04T
7500 4822 209 12636 TDA1320T/N1
HEADPHONE JACK
CIRCUIT BOARD
1800 BLK 4822 267 31453 HEADPHONES JACK
1800 GLD 4822 265 11062 HEADPHONES JACK
2801 5322 122 34099 470pF 10% X7R 63V
2802 5322 122 34099 470pF 10% X7R 63V
2803 4822 126 12882 100NF +80-20% 50V
OPTICAL OUT
CIRCUIT BOARD
2812 4822 126 13838 100NF Y5V 0805 50V P80M20
3960 4822 117 12521 68R 1% 0.1W
7802 4822 130 10845 GP1F32T OPT
