Marantz DV7010 - Microprocessor and IC Data

1-42
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
PE01-SCART
CIRCUIT BOARD
PE01-CAPACITORS
C801
17 /N 7010 /N 4822 124 90354 ELECT 100 F M 16V OA10701620
C804
C805
17 /N 7010 /N 4822 126 11703 CER. 0.01 F +80 -20% 50V DK98103300
C806
17 /N 7010 /N 9965 000 04997 CER. 5pF 0.25pF 50V DD90050300
C807
17 /N 7010 /N 9965 000 04997 CER. 5pF 0.25pF 50V DD90050300
C808
17 /N 7010 /N 4822 122 33782 CER. 56pF 5% 50V DD95560300
C809
17 /N 7010 /N 4822 122 33741 CER. 10pF 0.5pF 50V DD91100300
C810
17 /N 7010 /N 4822 122 33782 CER. 56pF 5% 50V DD95560300
C811
17 /N 7010 /N 4822 126 11703 CER. 0.01 F +80 -20% 50V DK98103300
C812
17 /N 7010 /N 9965 000 04997 CER. 5pF 0.25pF 50V DD90050300
C813
17 /N 7010 /N 9965 000 04997 CER. 5pF 0.25pF 50V DD90050300
C814
17 /N 7010 /N 4822 122 33782 CER. 56pF 5% 50V DD95560300
C815
17 /N 7010 /N 4822 122 33741 CER. 10pF 0.5pF 50V DD91100300
C816
17 /N 7010 /N 4822 122 33782 CER. 56pF 5% 50V DD95560300
C817
17 /N 7010 /N 5322 124 21731 ELECT 10 F M 50V OA10605020
C819
17 /N 7010 /N 4822 126 11703 CER. 0.01 F +80 -20% 50V DK98103300
C820
17 /N 7010 /N 9965 000 04997 CER. 5pF 0.25pF 50V DD90050300
C821
17 /N 7010 /N 9965 000 04997 CER. 5pF 0.25pF 50V DD90050300
C822
17 /N 7010 /N 4822 122 33782 CER. 56pF 5% 50V DD95560300
C823
17 /N 7010 /N 4822 122 33741 CER. 10pF 0.5pF 50V DD91100300
C824
17 /N 7010 /N 4822 122 33782 CER. 56pF 5% 50V DD95560300
C825
17 /N 7010 /N 4822 126 11704 CER. 0.022 F +80 -20% 50V DK98223300
C826
17 /N 7010 /N 4822 126 11703 CER. 0.01 F +80 -20% 50V DK98103300
C827
17 /N 7010 /N 9965 000 04997 CER. 5pF 0.25pF 50V DD90050300
C828
17 /N 7010 /N 9965 000 04997 CER. 5pF 0.25pF 50V DD90050300
C829
17 /N 7010 /N 4822 122 33782 CER. 56pF 5% 50V DD95560300
C830
17 /N 7010 /N 4822 122 33741 CER. 10pF 0.5pF 50V DD91100300
C831
17 /N 7010 /N 4822 122 33782 CER. 56pF 5% 50V DD95560300
C832
17 /N 7010 /N 5322 124 21731 ELECT 10 F M 50V OA10605020
C833
17 /N 7010 /N 4822 126 11703 CER. 0.01 F +80 -20% 50V DK98103300
C834
17 /N 7010 /N 9965 000 04997 CER. 5pF 0.25pF 50V DD90050300
C835
17 /N 7010 /N 9965 000 04997 CER. 5pF 0.25pF 50V DD90050300
C836
17 /N 7010 /N 4822 122 33782 CER. 56pF 5% 50V DD95560300
C837
17 /N 7010 /N 4822 122 33741 CER. 10pF 0.5pF 50V DD91100300
C838
17 /N 7010 /N 4822 122 33782 CER. 56pF 5% 50V DD95560300
C839
17 /N 7010 /N 5322 124 21731 ELECT 10 F M 50V OA10605020
C840
17 /N 7010 /N 4822 126 11703 CER. 0.01 F +80 -20% 50V DK98103300
C841
17 /N 7010 /N 9965 000 04997 CER. 5pF 0.25pF 50V DD90050300
C842
17 /N 7010 /N 9965 000 04997 CER. 5pF 0.25pF 50V DD90050300
C843
17 /N 7010 /N 4822 122 33782 CER. 56pF 5% 50V DD95560300
C844
17 /N 7010 /N 4822 122 33741 CER. 10pF 0.5pF 50V DD91100300
C845
17 /N 7010 /N 4822 122 33782 CER. 56pF 5% 50V DD95560300
C846
17 /N 7010 /N 5322 124 21731 ELECT 10 F M 50V OA10605020
C847
17 /N 7010 /N 4822 126 11703 CER. 0.01 F +80 -20% 50V DK98103300
C848
17 /N 7010 /N 4822 126 11703 CER. 0.01 F +80 -20% 50V DK98103300
C849
17 /N 7010 /N 4822 122 33777 CER. 47pF 5% CG 50V DD95470300
C850
17 /N 7010 /N 4822 122 33777 CER. 47pF 5% CG 50V DD95470300
C851
17 /N 7010 /N 4822 126 11703 CER. 0.01 F +80 -20% 50V DK98103300
C852
17 /N 7010 /N 4822 126 11703 CER. 0.01 F +80 -20% 50V DK98103300
C853
17 /N 7010 /N 4822 124 90354 ELECT 100 F M 16V OA10701620
C854
17 /N 7010 /N 4822 126 11704 CER. 0.022 F +80 -20% 50V DK98223300
C855
17 /N 7010 /N 4822 126 11703 CER. 0.01 F +80 -20% 50V DK98103300
C856
17 /N 7010 /N 4822 126 11703 CER. 0.01 F +80 -20% 50V DK98103300
C857
17 /N 7010 /N 4822 126 11703 CER. 0.01 F +80 -20% 50V DK98103300
C858
17 /N 7010 /N 4822 126 13303 CER. 1 F +80 -20% 10V DK98105200
C859
17 /N 7010 /N 4822 126 11703 CER. 0.01 F +80 -20% 50V DK98103300
C860
17 /N 7010 /N 4822 126 11703 CER. 0.01 F +80 -20% 50V DK98103300
C861
17 /N 7010 /N 4822 126 11703 CER. 0.01 F +80 -20% 50V DK98103300
C862
17 /N 7010 /N 4822 126 13303 CER. 1 F +80 -20% 10V DK98105200
C864
17 /N 7010 /N 4822 126 13883 CER. 220pF 5% 50V DD95221300
C865
17 /N 7010 /N 4822 126 11703 CER. 0.01 F +80 -20% 50V DK98103300
C867
17 /N 7010 /N 4822 126 11703 CER. 0.01 F +80 -20% 50V DK98103300
C869
17 /N 7010 /N 4822 126 11703 CER. 0.01 F +80 -20% 50V DK98103300
C870
17 /N 7010 /N 4822 126 13883 CER. 220pF 5% 50V DD95221300
C871
17 /N 7010 /N 4822 126 11703 CER. 0.01 F +80 -20% 50V DK98103300
C873
17 /N 7010 /N 4822 126 11687 CER. 0.1 F +80 -20% 25V DK98104200
C876
17 /N 7010 /N 4822 126 13883 CER. 220pF 5% 50V DD95221300
C877
17 /N 7010 /N 5322 124 21731 ELECT 10 F M 50V OA10605020
C879
17 /N 7010 /N 5322 124 21731 ELECT 10 F M 50V OA10605020
C881
17 /N 7010 /N 4822 126 13883 CER. 220pF 5% 50V DD95221300
C882
17 /N 7010 /N 4822 126 11703 CER. 0.01 F +80 -20% 50V DK98103300
C884
17 /N 7010 /N 4822 126 11687 CER. 0.1 F +80 -20% 25V DK98104200
C886
17 /N 7010 /N 5322 124 21731 ELECT 10 F M 50V OA10605020
C887
17 /N 7010 /N 4822 126 13303 CER. 1 F +80 -20% 10V DK98105200
C888
17 /N 7010 /N 4822 126 13303 CER. 1 F +80 -20% 10V DK98105200
C951
17 /N 7010 /N 4822 124 90354 ELECT 100 F M 16V OA10701620
C952
17 /N 7010 /N 4822 124 80067 ELECT 4.7 F M 50V OA47505020
C953
17 /N 7010 /N 4822 124 80067 ELECT 4.7 F M 50V OA47505020
C954
17 /N 7010 /N 4822 126 11703 CER. 0.01 F +80 -20% 50V DK98103300
C956
17 /N 7010 /N 4822 124 80067 ELECT 4.7 F M 50V OA47505020
C957
17 /N 7010 /N 4822 124 80067 ELECT 4.7 F M 50V OA47505020
C960
17 /N 7010 /N 4822 124 80067 ELECT 4.7 F M 50V OA47505020
C961
17 /N 7010 /N 4822 124 80067 ELECT 4.7 F M 50V OA47505020
C962
17 /N 7010 /N 4822 126 13883 CER. 220pF 5% 50V DD95221300
C963
17 /N 7010 /N 4822 126 13883 CER. 220pF 5% 50V DD95221300
C964
17 /N 7010 /N 4822 124 80067 ELECT 4.7 F M 50V OA47505020
C965
17 /N 7010 /N 4822 124 80067 ELECT 4.7 F M 50V OA47505020
C968
17 /N 7010 /N 4822 124 80067 ELECT 4.7 F M 50V OA47505020
C969
17 /N 7010 /N 4822 124 80067 ELECT 4.7 F M 50V OA47505020
C970
17 /N 7010 /N 4822 126 13883 CER. 220pF 5% 50V DD95221300
C971
17 /N 7010 /N 4822 126 13883 CER. 220pF 5% 50V DD95221300
C972
17 /N 7010 /N 4822 124 41539 ELECT 47 F M 16V OA47601620
C974
17 /N 7010 /N 5322 126 11578 CER. 1000pF 10% B 50V DK96102300
C977
PE01-RESISTORS
R801
17 /N 7010 /N 4822 051 30101 100 5% 1/16W NN05101610
R802
17 /N 7010 /N 4822 051 30681 680 5% 1/16W NN05681610
R803
17 /N 7010 /N 4822 051 30471 470 5% 1/16W NN05471610
R804
17 /N 7010 /N 4822 051 30223 22k 5% 1/16W NN05223610
R805
17 /N 7010 /N 4822 051 30101 100 5% 1/16W NN05101610
R806
17 /N 7010 /N 4822 051 30681 680 5% 1/16W NN05681610
R807
17 /N 7010 /N 4822 051 30471 470 5% 1/16W NN05471610
R808
17 /N 7010 /N 4822 051 30223 22k 5% 1/16W NN05223610
R809
17 /N 7010 /N 4822 051 30101 100 5% 1/16W NN05101610
R810
17 /N 7010 /N 4822 051 30681 680 5% 1/16W NN05681610
R811
17 /N 7010 /N 4822 051 30471 470 5% 1/16W NN05471610
R812
17 /N 7010 /N 4822 051 30223 22k 5% 1/16W NN05223610
R813
17 /N 7010 /N 4822 051 30101 100 5% 1/16W NN05101610
R814
17 /N 7010 /N 4822 051 30681 680 5% 1/16W NN05681610
R815
17 /N 7010 /N 4822 051 30471 470 5% 1/16W NN05471610
R816
17 /N 7010 /N 4822 051 30332 3.3k 5% 1/16W NN05332610
R817
17 /N 7010 /N 4822 051 30101 100 5% 1/16W NN05101610
R818
17 /N 7010 /N 4822 051 30681 680 5% 1/16W NN05681610
R819
17 /N 7010 /N 4822 051 30471 470 5% 1/16W NN05471610
R820
17 /N 7010 /N 4822 051 30332 3.3k 5% 1/16W NN05332610
R821
17 /N 7010 /N 4822 051 30101 100 5% 1/16W NN05101610
R822
17 /N 7010 /N 4822 051 30681 680 5% 1/16W NN05681610
R823
17 /N 7010 /N 4822 051 30471 470 5% 1/16W NN05471610
R824
17 /N 7010 /N 4822 051 30332 3.3k 5% 1/16W NN05332610
R825
17 /N 7010 /N 4822 051 30101 100 5% 1/16W NN05101610
R826
17 /N 7010 /N 4822 051 30101 100 5% 1/16W NN05101610
R827
17 /N 7010 /N 4822 051 30472 4.7k 5% 1/16W NN05472610
R828
17 /N 7010 /N 4822 051 30472 4.7k 5% 1/16W NN05472610
R829
17 /N 7010 /N 4822 051 30222 2.2k 5% 1/16W NN05222610
R830
17 /N 7010 /N 4822 051 30472 4.7k 5% 1/16W NN05472610
R831
17 /N 7010 /N 4822 051 30472 4.7k 5% 1/16W NN05472610
R832
17 /N 7010 /N 4822 117 13632 100k 5% 1/16W NN05104610
R833
17 /N 7010 /N 4822 051 30561 560 5% 1/16W NN05561610
