Marantz DV7010 - Exploded Views and Parts Lists

1-45
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
RF32 4822 051 30103 10k 5% 1/16W NN05103610
RF33 4822 051 30222 2.2k
5% 1/16W NN05222610
RF34 4822 051 30101 100
5% 1/16W NN05101610
RF35 4822 051 30101 100
5% 1/16W NN05101610
RF36 4822 051 30103 10k
5% 1/16W NN05103610
RF37 4822 051 30103 10k
5% 1/16W NN05103610
RF38 4822 116 83829 270
5% 1/16W NN05271610
RF39 4822 051 30103 10k
5% 1/16W NN05103610
RF40
17 18A 4822 116 83829 270 5% 1/16W NN05271610
RF40
7010 4822 051 30152 1.5k 5% 1/16W NN05152610
RF41
4822 051 30101 100 5% 1/16W NN05101610
RF44
RF45 4822 051 30472 4.7k
5% 1/16W NN05472610
RF46 4822 051 30472 4.7k
5% 1/16W NN05472610
RF47 4822 051 30472 4.7k
5% 1/16W NN05472610
RF48 4822 117 12864 82k
5% 1/16W NN05823610
RF49 4822 051 30472 4.7k
5% 1/16W NN05472610
RF50
18A /K,/U 4822 051 30103 10k 5% 1/16W NN05103610
RF50
7010 /U 4822 051 30103 10k 5% 1/16W NN05103610
RF51
17 ,/F,/S,/N 4822 051 30103 10k 5% 1/16W NN05103610
RF51
18A
/A,/C,/S,/L
4822 051 30103 10k 5% 1/16W NN05103610
RF51
7010 /A,/C,/F
/L,/N,/S
4822 051 30103 10k 5% 1/16W NN05103610
RF52
17 /S
7010 /A,/S
4822 051 30103 10k 5% 1/16W NN05103610
RF52
18A
/A,/C,/K,/S,/L
4822 051 30103 10k 5% 1/16W NN05103610
RF53
17 /F,/N
18A /U
4822 051 30103 10k 5% 1/16W NN05103610
RF53
7010
/A,/C,/L,/U
4822 051 30103 10k 5% 1/16W NN05103610
RF54
17 /S,/N 4822 051 30103 10k 5% 1/16W NN05103610
RF54
18A
/C,/K,/S,/L
4822 051 30103 10k 5% 1/16W NN05103610
RF54
7010
/C,/L,/N,/S
4822 051 30103 10k 5% 1/16W NN05103610
RF55
17 /F
18A /A,/U
4822 051 30103 10k 5% 1/16W NN05103610
RF55
7010 /A,/F,/U 4822 051 30103 10k 5% 1/16W NN05103610
RF56
4822 117 12864 82k 5% 1/16W NN05823610
RF59
RF60
17 /N 7010 /N 4822 051 30101 100 5% 1/16W NN05101610
RF61
17 /N 7010 /N 4822 051 30103 10k 5% 1/16W NN05103610
RF62
17 /N 7010 /N 4822 051 30103 10k 5% 1/16W NN05103610
RF63
17 /N 7010 /N 4822 051 30103 10k 5% 1/16W NN05103610
RF64
4822 051 30103 10k 5% 1/16W NN05103610
RF65
17 /S,/N 9965 000 03842 18 5% 1/16W NN05180610
RF65
18A
/A,/C,/K,/S
9965 000 03842 18 5% 1/16W NN05180610
RF65
7010
/A,/C,/N,/S
9965 000 03842 18 5% 1/16W NN05180610
PF01-SEMICONDUCTORS
DF01 9965 000 03119 CHIP DIODE ZENER
MA8033-H 3.3V
HZ30012020
DF02 9965 000 07629 CHIP DIODE MA8039-H HZ30025020
DF03 4822 130 83715 CHIP DIODE
1SS301 DAN202U
HZ21005000
DF04
17 18A 4822 130 11569 L.E.D. HLMF-K200
RED 3MM
HI10005340
DF05 4822 130 11569 L.E.D. HLMF-K200
RED 3MM
HI10005340
QF01
17 18A 9965 000 07630 MICROPROCESSOR
TMP87CM74AF
HU403KT000
QF01
7010 9965 000 07800 MICROPROCESSOR
MP87CM74AF
HU403KT00F
QF02 4822 130 10698 CHIP TRS. 2SA1586(Y GR)
2SA1576(Q R)
HX100012A0
QF03 4822 130 60669 CHIP TRS. 2SC4081(Q R)
2SC4116(Y GR)
HX300012A0
QF04 4822 209 15921 IC RESET IC S-806D-Z HC10077530
QF05 4822 130 60669 CHIP TRS. 2SC4081(Q R)
2SC4116(Y GR)
HX300012A0
QF06 4822 130 60669 CHIP TRS. 2SC4081(Q R)
2SC4116(Y GR)
HX300012A0
QF07 4822 130 10698 CHIP TRS. 2SA1586(Y GR)
2SA1576(Q R)
HX100012A0
QF08 4822 130 10698 CHIP TRS. 2SA1586(Y GR)
2SA1576(Q R)
HX100012A0
QF09 4822 130 61903 SEMICON.COMP
DTA114EUA
BA10026210
QF10 9965 000 04975 IC NJM79L24A -24V HC39124090
QF11 4822 130 10698 CHIP TRS. 2SA1586(Y GR)
2SA1576(Q R)
HX100012A0
QF12
17 /N 7010 /N 4822 130 61903 SEMICON.COMP
DTA114EUA
BA10026210
QF13
17 /N 7010 /N 4822 130 61906 SEMICON.COMP
DTC114EU
BA20035210
QF14
17 /N 7010 /N 4822 130 61906 SEMICON.COMP
DTC114EU
BA20035210
QF15
17 /N 7010 /N 4822 130 61906 SEMICON.COMP
DTC114EU
BA20035210
PF01-MISCELLANEOUS
JF01
18A
7010 /S,/U
JACK, 1MM PITCH FFC
HLW16R-2C7
YJ07013060
SF01
SF09
4822 276 13732 PUSH SWITCH SKQNAE
H/SMM 160GF
SP01013310
SF11 4822 276 13732 PUSH SWITCH SKQNAE
H/SMM 160GF
SP01013310
SF12 4822 276 13732 PUSH SWITCH SKQNAE
H/SMM 160GF
SP01013310
VF01 9965 000 07631 DISPLAY UNIT FL
11-BT-183
HQ31111410
XF01 9965 000 04977 SERAMIC VIB. CSTS
MG 8MHz
FQ08004060
ZF01 4822 130 11494 PHOTO UNIT IR-SENSOR
RPM6936-V4
HW10004210
PK01-HEADPHONE
CIRCUIT BOARD
PK01-CAPACITORS
CK01 4822 122 33777 CER. 47pF
5% 50V DD95470300
CK02 4822 122 33777 CER. 47pF
5% 50V DD95470300
CK03
17 18A 4822 124 23052 ELECT 100 F 16V EJ10701610
CK03
7010 4822 124 41539 ELECT 47 F M 16V OA47601620
CK04
17 18A 4822 124 23052 ELECT 100 F 16V EJ10701610
CK04
7010 4822 124 41539 ELECT 47 F M 16V OA47601620
CK07 4822 122 31765 CER. 100pF
5% 50V DD95101300
CK08 4822 122 31765 CER. 100pF
5% 50V DD95101300
CK09 4822 126 12339 CER. 2200pF
10% B 50V DK96222300
CK10 4822 126 11687 CER. 0.1
F +80 -20% 25V F DK98104200
PK01-RESISTORS CHIP
RK01 9965 000 00602 VARIABLE
RK09L12B0 10k
B
RM01031170
RK03 4822 051 30103 10k
5% 1/16W NN05103610
RK04 4822 051 30103 10k
5% 1/16W NN05103610
RK05 4822 051 30102 1k
5% 1/16W NN05102610
RK06 4822 051 30102 1k
5% 1/16W NN05102610
RK07 4822 051 30123 12k
5% 1/16W NN05123610
RK08 4822 051 30123 12k
5% 1/16W NN05123610
