NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
66
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
AUDIO Q737 00MHX600081A0 00MHX600081A0 CHIP TRS. KTA1517SGR HVTKTA1517SGR
AUDIO Q738 00MHX800081A0 00MHX800081A0 CHIP TRS. KTC3911SGR HVTKTC3911SGR
AUDIO Q740 00MHF201701G0 00MHF201701G0 F.E.T. FET
(
N-CH
)
AUDIO HVT2SK170BL
T
AUDIO Q741 90M-HF000070R 90M-HF000070R F.E.T. FET
(
P-CH
)
AUDIO HVT2SJ74BL
T
AUDIO Q742 90M-HX800050R 90M-HX800050R CHIP TRS. KRC402 HVTKRC402
AUDIO Q743 90M-HX800050R 90M-HX800050R CHIP TRS. KRC402 HVTKRC402
AUDIO Q744 90M-HT600050R 90M-HT600050R TRS. KTA2014GR HVTKTA2014GR
AUDIO Q745 00MHF203691B0 00MHF203691B0 F.E.T. FET
(
N-CH
)
AUDIO HVT2SK369BL
T
AUDIO Q746 00MHF203691B0 00MHF203691B0 F.E.T. FET
(
N-CH
)
AUDIO HVT2SK369BL
T
AUDIO Q747 90M-HX800060R 90M-HX800060R CHIP TRS. KTC4379Y HVTKTC4379Y
AUDIO Q748 00MHX600081A0 00MHX600081A0 CHIP TRS. KTA1517SGR HVTKTA1517SGR
AUDIO Q749 00MHX600081A0 00MHX600081A0 CHIP TRS. KTA1517SGR HVTKTA1517SGR
AUDIO Q750 00MHX800081A0 00MHX800081A0 CHIP TRS. KTC3911SGR HVTKTC3911SGR
AUDIO Q751 00MHF201701G0 00MHF201701G0 F.E.T. FET
(
N-CH
)
AUDIO HVT2SK170BL
T
AUDIO Q752 90M-HF000070R 90M-HF000070R F.E.T. FET
(
P-CH
)
AUDIO HVT2SJ74BL
T
AUDIO Q753 90M-HX800050R 90M-HX800050R CHIP TRS. KRC402 HVTKRC402
AUDIO Q754 90M-HX800050R 90M-HX800050R CHIP TRS. KRC402 HVTKRC402
AUDIO Q755 90M-HT600050R 90M-HT600050R TRS. KTA2014GR HVTKTA2014GR
AUDIO Q757 00MHF203691B0 00MHF203691B0 F.E.T. FET
(
N-CH
)
AUDIO HVT2SK369BL
T
AUDIO Q758 00MHF203691B0 00MHF203691B0 F.E.T. FET
(
N-CH
)
AUDIO HVT2SK369BL
T
AUDIO Q759 90M-HX800060R 90M-HX800060R CHIP TRS. KTC4379Y HVTKTC4379Y
AUDIO Q760 00MHX600081A0 00MHX600081A0 CHIP TRS. KTA1517SGR HVTKTA1517SGR
AUDIO Q761 00MHX600081A0 00MHX600081A0 CHIP TRS. KTA1517SGR HVTKTA1517SGR
AUDIO Q762 00MHX800081A0 00MHX800081A0 CHIP TRS. KTC3911SGR HVTKTC3911SGR
AUDIO Q763 00MHF201701G0 00MHF201701G0 F.E.T. FET
(
N-CH
)
AUDIO HVT2SK170BL
T
AUDIO Q764 90M-HF000070R 90M-HF000070R F.E.T. FET
(
P-CH
)
AUDIO HVT2SJ74BL
T
AUDIO Q765 90M-HX800050R 90M-HX800050R CHIP TRS. KRC402 HVTKRC402
AUDIO Q766 90M-HX800050R 90M-HX800050R CHIP TRS. KRC402 HVTKRC402
AUDIO Q767 90M-HT600050R 90M-HT600050R TRS. KTA2014GR HVTKTA2014GR
AUDIO Q768 00MHF203691B0 00MHF203691B0 F.E.T. FET
(
N-CH
)
AUDIO HVT2SK369BL
T
AUDIO Q769 00MHF203691B0 00MHF203691B0 F.E.T. FET
(
N-CH
)
AUDIO HVT2SK369BL
T
AUDIO Q770 90M-HX800060R 90M-HX800060R CHIP TRS. KTC4379Y HVTKTC4379Y
AUDIO Q771 00MHX600081A0 00MHX600081A0 CHIP TRS. KTA1517SGR HVTKTA1517SGR
AUDIO Q772 00MHX600081A0 00MHX600081A0 CHIP TRS. KTA1517SGR HVTKTA1517SGR
AUDIO Q773 00MHX800081A0 00MHX800081A0 CHIP TRS. KTC3911SGR HVTKTC3911SGR
AUDIO Q774 00MHF201701G0 00MHF201701G0 F.E.T. FET
(
N-CH
)
AUDIO HVT2SK170BL
T
AUDIO Q775 90M-HF000070R 90M-HF000070R F.E.T. FET
(
P-CH
)
AUDIO HVT2SJ74BL
T
AUDIO Q776 90M-HX800070R 90M-HX800070R CHIP TRS. KTC812TB HVTKTC812TB
AUDIO Q777 90M-HX800070R 90M-HX800070R CHIP TRS. KTC812TB HVTKTC812TB
AUDIO Q778 90M-HX800070R 90M-HX800070R CHIP TRS. KTC812TB HVTKTC812TB
AUDIO Q779 90M-HX800070R 90M-HX800070R CHIP TRS. KTC812TB HVTKTC812TB
AUDIO Q780 90M-HX800070R 90M-HX800070R CHIP TRS. KTC812TB HVTKTC812TB
AUDIO Q781 90M-HX800070R 90M-HX800070R CHIP TRS. KTC812TB HVTKTC812TB
AUDIO R101 ns
p
00MNN05105610 CHIP RES. 1 MOHM CRJ10DJ105
T
AUDIO R102 ns
p
00MNN05103610 CHIP RES. 10 KOHM CRJ10DJ103
T
AUDIO R104 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
AUDIO R105 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
AUDIO R106 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
AUDIO R107 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
AUDIO R108 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
AUDIO R109 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
AUDIO R110 ns
p
00MNN05101610 CHIP RES. 100 OHM CRJ10DJ101
T
AUDIO R111 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
AUDIO R112 ns
p
00MNN05101610 CHIP RES. 100 OHM CRJ10DJ101
T
AUDIO R113 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
AUDIO R115 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
AUDIO R116 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
AUDIO R117 ns
p
00MNN05103610 CHIP RES. 10 KOHM CRJ10DJ103
T
AUDIO R118 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
AUDIO R120 ns
p
00MNN05101610 CHIP RES. 100 OHM CRJ10DJ101
T
AUDIO R176 ns
p
00MNN05330610 CHIP RES. 33 OHM CRJ10DJ330
T
AUDIO R177 ns
p
00MNN05330610 CHIP RES. 33 OHM CRJ10DJ330
T
AUDIO R178 ns
p
00MNN05103610 CHIP RES. 10 KOHM CRJ10DJ103
T
AUDIO R179 ns
p
00MNN05103610 CHIP RES. 10 KOHM CRJ10DJ103
T
AUDIO R180 ns
p
00MNN05103610 CHIP RES. 10 KOHM CRJ10DJ103
T
AUDIO R181 ns
p
00MNN05103610 CHIP RES. 10 KOHM CRJ10DJ103
T
AUDIO R182 ns
p
00MNN05103610 CHIP RES. 10 KOHM CRJ10DJ103
T
