Marantz DV7600 - Page 63

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
78
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
MAIN C560 ns
p
00MOA10701620 ELECT. CAP. 100UF 16V ZF CCEA1CH101T
MAIN C561 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
MAIN C571 ns
p
00MOA10701620 ELECT. CAP. 100UF 16V ZF CCEA1CH101T
MAIN C572 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
MAIN C573 ns
p
00MDD95101300 CER. CAP. 100PF 50V JA 1608SIZE HCUS1H101JA
MAIN C574 ns
p
00MOA10701620 ELECT. CAP. 100UF 16V ZF CCEA1CH101T
MAIN C790 ns
p
00MOA22701620 ELECT. CAP. 220UF 16V CCEA1CH221T
MAIN C791 ns
p
00MOA33505020 ELECT. CAP. 3.3UF 50V CCEA1HH3R3T
MAIN C903 ns
p
00MOA10505020 ELECT. CAP. 1UF 50V CCEA1HH1R0T
MAIN C904 ns
p
00MOA10605020 ELECT. CAP. 10UF 50V ZF CCEA1HH100T
MAIN C909 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
MAIN C910 ns
p
00MOA47602520 ELECT. CAP. 47UF 25V CCEA1EH470T
MAIN C911 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
MAIN C912 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
MAIN C913 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
MAIN C914 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
MAIN C916 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
MAIN C917 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
MAIN C918 ns
p
00MOA10701620 ELECT. CAP. 100UF 16V ZF CCEA1CH101T
MAIN C919 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
MAIN C920 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
MAIN C921 ns
p
00MOA10701620 ELECT. CAP. 100UF 16V ZF CCEA1CH101T
MAIN C922 ns
p
00MOA10701620 ELECT. CAP. 100UF 16V ZF CCEA1CH101T
MAIN C923 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
MAIN C927 ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC 1608SIZE HCUS1H102KC
MAIN C928 ns
p
00MOA47602520 ELECT. CAP. 47UF 25V CCEA1EH470T
MAIN C930 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
MAIN C931 ns
p
00MOA47602520 ELECT. CAP. 47UF 25V CCEA1EH470T
MAIN C932 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
MAIN C935 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
MAIN C936 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
MAIN C937 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
MAIN C983
/
L1G ns
p
90M-EY000450R TANTL.CAP CHIP TANTALUM, 22U/6.3V B,20% HCSHB20J220B
MAIN C983
/
U1B ns
p
90M-EY000450R TANTL.CAP CHIP TANTALUM, 22U/6.3V B,20% HCSHB20J220B
MAIN C984
/
L1G ns
p
90M-EY000450R TANTL.CAP CHIP TANTALUM, 22U/6.3V B,20% HCSHB20J220B
MAIN C984
/
U1B ns
p
90M-EY000450R TANTL.CAP CHIP TANTALUM, 22U/6.3V B,20% HCSHB20J220B
MAIN CN15 ns
p
ns
p
JACK DUAL 12P
(
2MM PITCH
)
CJP12GA147Z
Y
MAIN CN21 ns
p
ns
p
JACK WAFER , CARD CABLE KJP27GA117ZG
MAIN CN70 ns
p
ns
p
JACK WAFER, STRAIGHT, 7PIN CJP07GA01Z
Y
MAIN CX11 90M-YJ002850R 90M-YJ002850R JACK FPC WAFER 0.5MM PITCH KJP40GA195ZM
MAIN CX12 ns
p
ns
p
JACK WAFER , CARD CABLE CJP15GA117Z
Y
MAIN CY41 ns
p
ns
p
JACK GF102-17S-TS KJP17GA117ZG
MAIN D105 00MHZ20002210 00MHZ20002210 CHIP DIODE DAN202
K
BVDDAN202
K
MAIN D201 00MHZ20002210 00MHZ20002210 CHIP DIODE DAN202
K
BVDDAN202
K
MAIN D701 00MHZ20056210 00MHZ20056210 CHIP DIODE DAN217 T146
(
SMD3
)
BVDDAN217
MAIN D706 00MHZ20002210 00MHZ20002210 CHIP DIODE DAN202
K
BVDDAN202
K
MAIN D901 00MHZ20002210 00MHZ20002210 CHIP DIODE DAN202
K
BVDDAN202
K
MAIN D904 00MHZ20002210 00MHZ20002210 CHIP DIODE DAN202
K
BVDDAN202
K
MAIN D905 00MHZ20002210 00MHZ20002210 CHIP DIODE DAN202
K
BVDDAN202
K
MAIN D906 00MHZ20002210 00MHZ20002210 CHIP DIODE DAN202
K
BVDDAN202
K
MAIN ET51 ns
p
ns
p
BRACKET BRACKET , PWB CMD1A387
MAIN ET52 ns
p
ns
p
TERMINAL PLATE , EARTH CMC1A111
MAIN IC11 00MHC10089840 00MHC10089840 IC VIDEO ENCORDER HVIADV7310
MAIN IC12
/
N1B 00MHC10089840 00MHC10089840 IC VIDEO ENCORDER HVIADV7310
MAIN IC12
/
N1S 00MHC10089840 00MHC10089840 IC VIDEO ENCORDER HVIADV7310
MAIN IC13 90M-HC109360R 90M-HC109360R IC HI-SPEED 2 INPUT AND GATE HVIKIC7SH08FU
MAIN IC14 00MHC10228210 00MHC10228210 IC REGULATOR 2.5V
(
TO252-5
)
BVIBA25BC0WFPE2
MAIN IC20 90M-HC109380R 90M-HC109380R IC VIDEO DRIVER
(
SOP-16C
)
HVIMM1566AFBE
MAIN IC21
/
N1B 00MHC10102550 00MHC10102550 IC VIDEO DRIVER
(
SOP-28D
)
HVIMM1623XFBE
MAIN IC21
/
N1S 00MHC10102550 00MHC10102550 IC VIDEO DRIVER
(
SOP-28D
)
HVIMM1623XFBE
MAIN IC22
/
N1B 00MHC12244090 00MHC12244090 IC VIDEO SWITCH
(
DMP16
)
HVINJM2584MTE1
MAIN IC22
/
N1S 00MHC12244090 00MHC12244090 IC VIDEO SWITCH
(
DMP16
)
HVINJM2584MTE1
MAIN IC23 90M-HZ300070R 90M-HZ300070R CHIP DIODE REGULATOR 5V
(
TO252-5
)
BVIBA05CC0WFPE2
MAIN IC24 00MHC10231090 00MHC10231090 IC TRIPLE VIDEO AMPLIFIER HVINJM2580MTE1
MAIN IC46 00MHC10228210 00MHC10228210 IC REGULATOR 2.5V
(
TO252-5
)
BVIBA25BC0WFPE2
MAIN IC47 90M-HC109360R 90M-HC109360R IC HI-SPEED 2 INPUT AND GATE HVIKIC7SH08FU
MAIN IC51 00MHC10019660 00MHC10019660 IC I/P CONVERTER
(
LQFP-144
)
HVICD0040AF
