Marantz PM4000 User Manual

50
Figure 1
OUTINOUTIN
TAPECD-R/MDAUXTUNERCD
R L
R L
SYSTEM 2
SYSTEM 1
SPEAKER SYSTEMS
SYSTEM 1 : 4 -16 OHMS
SYSTEM 2 : 4 -16 OHMS
SYSTEM 1+2 : 8 -16 OHMS
L
R
PHONO
GND
Tighten the terminal
5 mm
Loosen the terminal Inset the core
Connection of speaker cable
CD player
Analogur output jacks or
AV components, video disc player, etc.
Tape deck
Tape deck
Tuner
Turntable
OUTPUT
OUTPUT
OUTPUT
OUTPUT
OUTPUT
INPUT
INPUT
R L
R L
SYSTEM1
SYSTEM2
SPEAKER SYSTEMS
SYSTEM 1 : 8 -16 OHMS
SYSTEM 2 : 8 -16 OHMS
SYSTEM 1+2 : 16 OHMS
