Marantz PM4001 - Page 27

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
33
PM4001
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
INPUT R346 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R347 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R348 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R349 ns
p
ns
p
RES. 47 OHM 1/5W J CRD20TJ470
T
INPUT R350 ns
p
ns
p
RES. 47 OHM 1/5W J CRD20TJ470
T
INPUT R351 ns
p
ns
p
RES. 47 OHM 1/5W J CRD20TJ470
T
INPUT R352 ns
p
ns
p
RES. 47 OHM 1/5W J CRD20TJ470
T
INPUT R353 ns
p
ns
p
RES. 220 OHM 1/4W J CRD25TJ221
T
INPUT R354 ns
p
ns
p
RES. 220 OHM 1/4W J CRD25TJ221
T
INPUT R355 ns
p
ns
p
RES. 10 OHM 1/5W J CRD20TJ100
T
INPUT R356 ns
p
ns
p
RES. 10 OHM 1/5W J CRD20TJ100
T
INPUT R357 ns
p
ns
p
RES. 10 OHM 1/4W J CRD25TJ100
T
INPUT R358 ns
p
ns
p
RES. 10 OHM 1/5W J CRD20TJ100
T
INPUT R359 90M-GO000005R 90M-GO000005R RES. 0.22 OHM 5W
K
CRF5EKR22H
INPUT R360 90M-GO000005R 90M-GO000005R RES. 0.22 OHM 5W
K
CRF5EKR22H
INPUT R361 90M-GO000005R 90M-GO000005R RES. 0.22 OHM 5W
K
CRF5EKR22H
INPUT R362 90M-GO000005R 90M-GO000005R RES. 0.22 OHM 5W
K
CRF5EKR22H
INPUT R363 ns
p
ns
p
RES. 10 OHM 1/4W J CRD25TJ100
T
INPUT R364 ns
p
ns
p
RES. 10 OHM 1/4W J CRD25TJ100
T
INPUT R365 ns
p
ns
p
RES. 10 OHM 1/4W J CRD25TJ100
T
INPUT R366 ns
p
ns
p
RES. 10 OHM 1/4W J CRD25TJ100
T
INPUT R367 ns
p
ns
p
RES. 10 OHM CRG1ANJ100H
INPUT R368 ns
p
ns
p
RES. 10 OHM CRG1ANJ100H
INPUT R371 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102
T
INPUT R372 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102
T
INPUT R373 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223
T
INPUT R374 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223
T
INPUT R375 ns
p
ns
p
RES. 1.5K OHM 1/5W J CRD20TJ152
T
INPUT R376 ns
p
ns
p
RES. 1.5K OHM 1/5W J CRD20TJ152
T
INPUT R377 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223
T
INPUT R378 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223
T
INPUT R379 ns
p
ns
p
RES. 6.8K OHM 1/5W J CRD20TJ682
T
INPUT R381 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333
T
INPUT R382 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333
T
INPUT R383 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223
T
INPUT R385 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R386 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R387 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R388 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333
T
INPUT R389 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333
T
INPUT R390 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R391 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333
T
INPUT R392 ns
p
ns
p
RES. 18K OHM 1/5W J CRD20TJ183
T
INPUT R393 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R394 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R395 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R396 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R397 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R398 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R399 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R400 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R691 ns
p
ns
p
RES. 330 OHM 1
W
CRG1ANJ331H
INPUT R692 ns
p
ns
p
RES. 330 OHM 1
W
CRG1ANJ331H
INPUT R901 ns
p
ns
p
RES. 4.7K OHM 1/4W J CRD25TJ472
T
INPUT R905 ns
p
ns
p
RES. 22K OHM 1/4W J CRD25TJ223
T
INPUT R906 ns
p
ns
p
RES. 22K OHM 1/4W J CRD25TJ223
T
INPUT R911 90M-NH000080R 90M-NH000080R FUSE RES. ! 0.47 OHM 1W J KRQ1AJR47H
INPUT R912 90M-NH000080R 90M-NH000080R FUSE RES. ! 0.47 OHM 1W J KRQ1AJR47H
INPUT R913 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472
T
INPUT R914 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223
T
INPUT R915 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R919 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223
T
INPUT R920 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223
T
INPUT R921 ns
p
ns
p
RES. 1.2K OHM 1/5W J CRD20TJ122
T
INPUT R922 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102
T
INPUT R923 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333
T
INPUT R924 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223
T
