Marantz PM4001 - Page 41

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
47
PM4001 OSE
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
INPUT R214 ns
p
ns
p
RES. 10 OHM 1/5W J CRD20TJ100
T
INPUT R221 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105
T
INPUT R222 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105
T
INPUT R223 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105
T
INPUT R224 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105
T
INPUT R225 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105
T
INPUT R226 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105
T
INPUT R227 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105
T
INPUT R228 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105
T
INPUT R229 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105
T
INPUT R230 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105
T
INPUT R231 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105
T
INPUT R232 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105
T
INPUT R233 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105
T
INPUT R234 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105
T
INPUT R235 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102
T
INPUT R236 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102
T
INPUT R237 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102
T
INPUT R238 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102
T
INPUT R251 ns
p
ns
p
RES. 120 OHM 1/5W J CRD20TJ121
T
INPUT R252 ns
p
ns
p
RES. 120 OHM 1/5W J CRD20TJ121
T
INPUT R253 ns
p
ns
p
RES. 120 OHM 1/5W J CRD20TJ121
T
INPUT R254 ns
p
ns
p
RES. 120 OHM 1/5W J CRD20TJ121
T
INPUT R255 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R256 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R258 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R260 ns
p
ns
p
RES. 56K OHM 1/5W J CRD20TJ563
T
INPUT R261 ns
p
ns
p
RES. 56K OHM 1/5W J CRD20TJ563
T
INPUT R264 ns
p
ns
p
RES. 27K OHM 1/5W J CRD20TJ273
T
INPUT R265 ns
p
ns
p
RES. 27K OHM 1/5W J CRD20TJ273
T
INPUT R266 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331
T
INPUT R267 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331
T
INPUT R269 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R270 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R273 ns
p
ns
p
RES. 120 OHM 1/5W J CRD20TJ121
T
INPUT R274 ns
p
ns
p
RES. 120 OHM 1/5W J CRD20TJ121
T
INPUT R275 ns
p
ns
p
RES. 120 OHM 1/5W J CRD20TJ121
T
INPUT R280 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R281 ns
p
ns
p
RES. 470K OHM 1/5W J CRD20TJ474
T
INPUT R282 ns
p
ns
p
RES. 470K OHM 1/5W J CRD20TJ474
T
INPUT R283 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105
T
INPUT R284 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104
T
INPUT R285 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104
T
INPUT R286 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471
T
INPUT R287 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471
T
INPUT R288 ns
p
ns
p
RES. 680 OHM 1/5W J CRD20TJ681
T
INPUT R289 ns
p
ns
p
RES. 680 OHM 1/5W J CRD20TJ681
T
INPUT R290 ns
p
ns
p
RES. 5.6K OHM 1/5W J CRD20TJ562
T
INPUT R291 ns
p
ns
p
RES. 5.6K OHM 1/5W J CRD20TJ562
T
INPUT R292 ns
p
ns
p
RES. 5.6K OHM 1/5W J CRD20TJ562
T
INPUT R293 ns
p
ns
p
RES. 5.6K OHM 1/5W J CRD20TJ562
T
INPUT R294 ns
p
ns
p
RES. 1.5K OHM 1/5W J CRD20TJ152
T
INPUT R295 ns
p
ns
p
RES. 1.5K OHM 1/5W J CRD20TJ152
T
INPUT R296 ns
p
ns
p
RES. 1.5K OHM 1/5W J CRD20TJ152
T
INPUT R297 ns
p
ns
p
RES. 1.5K OHM 1/5W J CRD20TJ152
T
INPUT R298 ns
p
ns
p
RES. 270 OHM 1/5W J CRD20TJ271
T
INPUT R299 ns
p
ns
p
RES. 270 OHM 1/5W J CRD20TJ271
T
INPUT R300 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333
T
INPUT R301 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333
T
INPUT R302 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472
T
INPUT R303 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472
T
INPUT R304 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331
T
INPUT R305 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331
T
INPUT R306 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104
T
INPUT R307 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104
T
INPUT R308 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471
T
INPUT R309 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471
T
