Marantz PM4001 - Page 43

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
49
PM4001 OSE
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
INPUT R383 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223
T
INPUT R385 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R386 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R387 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R388 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333
T
INPUT R389 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333
T
INPUT R390 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R391 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333
T
INPUT R392 ns
p
ns
p
RES. 18K OHM 1/5W J CRD20TJ183
T
INPUT R393 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R394 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R395 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R396 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R397 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R398 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R399 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R400 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R691 ns
p
ns
p
RES. 330 OHM 1
W
CRG1ANJ331H
INPUT R692 ns
p
ns
p
RES. 330 OHM 1
W
CRG1ANJ331H
INPUT R901 ns
p
ns
p
RES. 4.7K OHM 1/4W J CRD25TJ472
T
INPUT R905 ns
p
ns
p
RES. 22K OHM 1/4W J CRD25TJ223
T
INPUT R906 ns
p
ns
p
RES. 22K OHM 1/4W J CRD25TJ223
T
INPUT R911 90M-NH000080R 90M-NH000080R FUSE RES. ! 0.47 OHM 1W J KRQ1AJR47H
INPUT R912 90M-NH000080R 90M-NH000080R FUSE RES. ! 0.47 OHM 1W J KRQ1AJR47H
INPUT R913 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472
T
INPUT R914 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223
T
INPUT R915 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R919 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223
T
INPUT R920 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223
T
INPUT R921 ns
p
ns
p
RES. 1.2K OHM 1/5W J CRD20TJ122
T
INPUT R922 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102
T
INPUT R923 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333
T
INPUT R924 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223
T
INPUT R925 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223
T
INPUT R926 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223
T
INPUT R927 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R928 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R929 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT RY31 90M-LY000330R 90M-LY000330R RELAY OSA-SS-212DM3 HSL4A004ZU
INPUT RY32 90M-LY000330R 90M-LY000330R RELAY OSA-SS-212DM3 HSL4A004ZU
INPUT RY33 90M-LY000330R 90M-LY000330R RELAY OSA-SS-212DM3 HSL4A004ZU
INPUT VR31 90M-RA001080R 90M-RA001080R TRIM. RES. RH0638C-471 HVN1RA471B01
T
INPUT VR32 90M-RA001080R 90M-RA001080R TRIM. RES. RH0638C-471 HVN1RA471B01
T
INPUT VR33 90M-RA001140R 90M-RA001140R TRIM. RES. RH0638C-102 HVN1RA102B01
T
INPUT VR34 90M-RA001140R 90M-RA001140R TRIM. RES. RH0638C-102 HVN1RA102B01
T
MAIN TRANSF. PWB
(
CUP11833-3
)
MAIN-T C910 ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
MAIN-T CN91 ns
p
ns
p
CONN. 6P ANGLE CJP06GB03Z
Y
MAIN-T CN92 ns
p
ns
p
CONN. 4P ANGLE CJP04GB03Z
Y
MAIN-T JW93 ns
p
ns
p
CORD WIRE ASSY CWZAMC660JW52
MASTER VOLUME PWB
(
CUP11832-2
)
M-VOL. BN12 ns
p
ns
p
CORD WIRE ASSY 2.5MM
(
04P
)
SHIELD CWZPM48BN33
M-VOL. BN53 90M-YJ002920R 90M-YJ002920R CONN. 6P ANGLE CJP06GB99Z
Y
M-VOL. C527 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
M-VOL. C543
/
N1B ns
p
00MOA106035Z0 ELECT CAP. 10UF 35V ROS HCEA1VR100T
M-VOL. C543
/
N1S ns
p
00MOA106035Z0 ELECT CAP. 10UF 35V ROS HCEA1VR100T
M-VOL. C544
/
N1B ns
p
00MOA106035Z0 ELECT CAP. 10UF 35V ROS HCEA1VR100T
M-VOL. C544
/
N1S ns
p
00MOA106035Z0 ELECT CAP. 10UF 35V ROS HCEA1VR100T
M-VOL. CB52 90M-YP100330R 90M-YP100330R CONN. 7P ANGLE CJP07GF107Z
Y
M-VOL. J116 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
M-VOL. J303 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
M-VOL. J306 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
M-VOL. J327 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
M-VOL. J501 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
M-VOL. J503 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
M-VOL. J506 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
M-VOL. J901 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
