NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
51
PM4001 OSE
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
U-PRO BN52 90M-YJ002930R 90M-YJ002930R CONN. 7P STRAIGHT KJP07HA37ZM
U-PRO BN93 ns
p
ns
p
CORD CWB2B905280EN
U-PRO BN95 ns
p
ns
p
CORD CWB2B910300EN
U-PRO C501 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
U-PRO C502 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
U-PRO C503 ns
p
ns
p
CER. CAP. 100PF 50V
K
HCBS1H101KBT
U-PRO C504 ns
p
ns
p
CER. CAP. 100PF 50V
K
HCBS1H101KBT
U-PRO C505 ns
p
00MOA22605020 ELECT CAP. 22UF 50V CCEA1HH220T
U-PRO C506 ns
p
00MOA22605020 ELECT CAP. 22UF 50V CCEA1HH220T
U-PRO C507 ns
p
00MOA47601640 ELECT CAP. 47UF 16V CCEA1CH470T
U-PRO C508 ns
p
00MOA47601640 ELECT CAP. 47UF 16V CCEA1CH470T
U-PRO C509 ns
p
ns
p
CER. CAP. 33PF 50V J HCBS1H330JT
U-PRO C510 ns
p
ns
p
CER. CAP. 33PF 50V J HCBS1H330JT
U-PRO C511 ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V CCEA1HH4R7T
U-PRO C512 ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V CCEA1HH4R7T
U-PRO C513 ns
p
ns
p
FILM CAP. 0.033UF 50V J HCQI1H333JZT
U-PRO C514 ns
p
ns
p
FILM CAP. 0.033UF 50V J HCQI1H333JZT
U-PRO C515 ns
p
ns
p
FILM CAP. 0.015UF 50V J HCQI1H153JZT
U-PRO C516 ns
p
ns
p
FILM CAP. 0.015UF 50V J HCQI1H153JZT
U-PRO C517 ns
p
ns
p
CER. CAP. 220PF 50V
K
HCBS1H221KBT
U-PRO C518 ns
p
ns
p
CER. CAP. 220PF 50V
K
HCBS1H221KBT
U-PRO C530
/
N1B ns
p
00MOA22701620 ELECT CAP. 220UF 16V RA-2 HCEA1CRA221T
U-PRO C530
/
N1S ns
p
00MOA22701620 ELECT CAP. 220UF 16V RA-2 HCEA1CRA221T
U-PRO C531
/
N1B ns
p
00MOA22701620 ELECT CAP. 220UF 16V RA-2 HCEA1CRA221T
U-PRO C531
/
N1S ns
p
00MOA22701620 ELECT CAP. 220UF 16V RA-2 HCEA1CRA221T
U-PRO C541 ns
p
00MOA22605020 ELECT CAP. 22UF 25V CCEA1EH220T
U-PRO C542 ns
p
00MOA22605020 ELECT CAP. 22UF 25V CCEA1EH220T
U-PRO C548 ns
p
ns
p
CER. CAP. 100PF 50V
K
HCBS1H101KBT
U-PRO C549 ns
p
ns
p
CER. CAP. 100PF 50V
K
HCBS1H101KBT
U-PRO C601 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
U-PRO C602 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
U-PRO C606 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
U-PRO C611 ns
p
00MOA22701620 ELECT CAP. 220UF 16V CCEA1CH221T
U-PRO C612 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
U-PRO C613 ns
p
00MOA22701620 ELECT CAP. 220UF 16V CCEA1CH221T
U-PRO C617 ns
p
ns
p
CER. CAP. 100PF 50V
K
HCBS1H101KBT
U-PRO C618 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
U-PRO C619 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
U-PRO C620 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
U-PRO C621 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
U-PRO C622 ns
p
00MOA22701620 ELECT CAP. 220UF 16V CCEA1CH221T
U-PRO C623 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
U-PRO C625 ns
p
ns
p
CER. CAP. 33PF 50V JC CCCT1H330JC
U-PRO C626 ns
p
ns
p
CER. CAP. 33PF 50V JC CCCT1H330JC
U-PRO C627 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
U-PRO C681 ns
p
00MOA22701620 ELECT CAP. 220UF 16V CCEA1CH221T
U-PRO C687 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
U-PRO C688 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
U-PRO C693 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
U-PRO C694 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
U-PRO C695 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
U-PRO D601 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
U-PRO D606 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
U-PRO D613 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
U-PRO D621 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
U-PRO D622 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
U-PRO D623 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
U-PRO D651 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
U-PRO D652 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
U-PRO D653 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
U-PRO D654 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
U-PRO D655 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
U-PRO D656 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
U-PRO D657 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
U-PRO D675 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
U-PRO IC52
/
N1B 90M-HC109460R 90M-HC109460R IC NJM2114M HVINJM2114M
U-PRO IC52
/
N1S 90M-HC109460R 90M-HC109460R IC NJM2114M HVINJM2114M
