PM4400 OSE
Design and specifications are subject
to change by Marantz without notice
www.marantz.com
Preliminary Specifications
FEATURES
Channels 2
Current Feedback Topology -
Class A amplification -
Linear drive power supply -
CCNE -
Power Transformer EI
HDAM -
Symmetric PCB layout •
Copper Plated Chassis -
High grade audio components •
Customized Components •
BTL possibility -
Balance / Bass / Treble / Loudness •/•/•/•
Source Direct •
Separate solid heat sinks -
Speaker A/B •
Record selector: full / copy-source •/-
Tape monitor •
Temperature gauge -
Standby mode •
INPUTS/OUTPUTS
Audio Inputs 6
Phono input: MM/MC •/-
Audio Outputs -
Balanced in- / output -/-
External Control In (Composite) -
Processor I/O -
Pre-out / Main-in -/-
D-Bus In & Out •
Gold plated cinch -
Speaker Terminal: Heavy Duty Screw
AC Outlets (Not for UK Model) -
Headphone out •
AUDIO SPECIFICATIONS
Power Output (8/4 Ohm RMS) 30/40 Watts
Power Output (8/4 Ohm DIN) 35/45 Watts
Power Output (8/4 Ohm IHF) 50/80W
Frequency Response 10Hz-50kHz (+0,-1dB)
Total Harmonic Distortion 0.005%
Bridged Power Output (8 Ohm RMS) -
Damping Factor 80
Input Sensitivity: MM 2.5 mV / 47 kOhm
Input Sensitivity: MC -
Input Sensitivity: High level 150mV /20kOhm
Signal to Noise Ratio MM/MC/High Level
80/-/105 dB
Channel separation: 1kHz / 10kHz 70/- dB
GENERAL
Color Black / Gold
Metal Front Panel -
Remote Functions System
Remote control RC4200PM
Power Consumption 100W
Detachable Power Cable -
Maximum dimensions (W x H x D)
440 x 116 x 343 mm
Weight 6.0 kg
