RECORD
LEVEL
CONTROLS
To
increase
The
recording
levels,
turn the
knob
to
the
right.
REC
INDICATOR
When
your unit
is
recording,
this
indicator
will
light up
red.
1LOW
BATTERY
INDICATOR
When
the
batteries
are
exhausted,
this
indicator
lights.
When
the
battery
condition
is
satisfactory,
this
indicator
remains
off.
Z)
MEMORY
REW
SWITCH
(For
Model
PMD221)
When the
tape
is
rewound
with
the
MEMORY
REW
switch
set to
ON,
tape
travel
stops
when
the
counter
reaches
"999".
PITCH
CONTROL
When
the
PITCH
control
knob
is at
the
"0"
position, it
is
set at
normal
speed.
Turn
it
in the
H
direction to
increase
the
tape
speed.
Turn
it in
the L
direction
to
decrease
the
tape
speed.
IVU
METER
The
VU
meter
indicates
the
average
recording/playback
level.
(f|)
REC
MODE
SWITCH
MANUAL:
At
this
setting,
the
recording
level
can be
adjusted
manually
to
your
preference.
LIMITER:
At
this
setting,
the
transient
high
level
input
signals
are
automatically
decreased
to
a
safe
recording
level.
ALC:
At
this
setting,
the
recording
level
is
automati-
cally
set
to
optimum
level.
LEVEL
CONTROL
The
LEVEL
control
regulates
the
sound
volume
heard
through
the
speaker
or
headphone.
PHONE
JACK
Accepts
headphones
(optional)
utilizing
a
standard
stereo
or
mono
phone
plug.
MICROPHONE
ATTENUATOR
SWITCH
For
extremely
loud
volume
microphone
recordings,
depress-
ing
this
switch
prevents
input
overload
and
better
record
level
adjustment.
.
This
switch
also
functions
for
direct
telephone
or
built-in
microphone
recording.
MICROPHONE
JACKS
Will
accept
any
low
impedance
microphone
(optional)
utilizing
a
3.5 mm
phone
plug.
NOTE:
When
microphones
are
selected
for
recording
do
not
monitor
through
speakers as
this
will
cause
howling
(acoustic
feed-
back)
which
could
damage
your
audio
equipment.
Use
head-
phones
for
monitoring.
LINE
INPUT
Should be
connected
to
the
tape
output
jacks
of
your
ampli-
fier.
LINE
OUTPUT
Should
be
connected
to
the
tape
monitor
inputs
of
your
amplifier.
SPEAKER
ON/OFF
SWITCH
(SPKR
MON)
Place
this
switch
in
the
ON
position
to
monitor
recordings
through
the
built-in
speaker.
EXTERNAL
DC
POWER
INPUT
JACK
(DC 4.5
V)
This
jack is
provided
to
operate
your
portable
cassette
recorder
from
an
external
4.5
volt DC
power
source.
!
EXT
SP
JACK
Accesses the
3.5 mm
plug
of
an
external
speaker.
I
TONE
CONTROL
Used
to
adjust
the
sound
quality
heard
through
the
speaker,
headphone
or
direct
telephone
system.
When
the
knob «
turned
counterclockwise,
the
low
frequency
sound
.s
de-
creased.
When
the
knob
is
turned
clockwise,
the
high
fre-
quency
"sound
is
increased.
MONITOR
SWITCH
(For
Model
PMD221)
When
recording,
this
switch
may
be
placed
in
the
SOURCE
position
to
monitor
the
signal
before
it is
recorded
or the
TAPE
position to
monitor
the
signal
actually
recorded
on
the
tape.
NOTE:
When
the
MONITOR
switch
is
set to
SOURCE,
howling
may
occur.
At
that
time,
lower
the
monitoring
volume.
TAPE
SPEED
SELECTOR
STANDARD:
The
tape
travels
at
normal
speed:
1-7/8
ips
(4.75
cm
/sec).
LOW:
The
tape
travels
are
slower
speed:
15/16
ips
(2.38
cm/sec).
REMOTE
JACK
This
jack
accesses
a
2.5
mm
plug.
With a
microphone
equipped
with a
remote
switch,
playback
or
recording
can be
stopped
temporarily.
@
TELEPHONE
PICK-UP
JACK
This
jack
accesses
the
telephone
pick-up
for
telephone
recording.
DIRECT
TELEPHONE
MODULAR
JACK
With a
telephone
line
connected
to
the
direct
telephone
modular
jack,
it
is
possible
to
record
messages
and
play
pre-
recorded
messages
back
through
the
telephone
line.
ANC
SELECTOR
Used
to
select
flat
(NORMAL),
low
cut
I
f~
)
or
high
and
tow
cut
(
r\
)
modes
for a
microphone,
telephone
pick-up
or
direct
telephone
recording
according
to
the
signal
condition.
INPUT
SELECTOR
Used to
select
an
input
signal
between
LINE,
MIC/TEL
and
DIRECT
TELEPHONE.
