NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
001B 99M340J248410 99M340J248410 FRONT PANEL FRONT PANEL ASSY
002B 00M340J248120 00M340J248120 FRONT PANEL FRONT PANEL
003B 00M340J063110 00M340J063110 ESCUTCHEON ESCUTCHEON LEFT
004B 00M340J063120 00M340J063120 ESCUTCHEON ESCUTCHEON RIGHT
006B 00M339J353210 00M339J353210 RING RING FOR METER
007B 00M339J158010 00M339J158010 WINDOW WINDOW FOR METER
008B 00M339J353120 00M339J353120 RING RING FOR POWER SWITCH
009B 00M340J355010 00M340J355010 LENS LENS FOR IR
010B 00M269J355010 00M269J355010 LENS LENS INPUT SEL / ATT
015B 00M339J270110 00M339J270110 BUTTON BUTTON POWER SWITCH
020B 00M340J270110 00M340J270110 BUTTON BUTTON DISPLAY / ATT
024B 00M339J355020 00M339J355020 LENS LENS STAR MARK
025B 00M340J355020 00M340J355020 LENS LENS A/B/SYNC
027B 00M339J355010 00M339J355010 LENS LENS SIDE LIGHTING
033B 00M340J154110 00M340J154110 KNOB KNOB INPUT SEL / VOLUME
041B 00M04AJ251010 00M04AJ251010 BADGE BADGE
(
MARANTZ
)
078B 00M04AJ112110 00M04AJ112110 SHAFT VOLUME SHAFT
001D 00M340J249110 00M340J249110 SIDE PANEL SIDE PANEL LEFT
002D 00M340J249120 00M340J249120 SIDE PANEL SIDE PANEL RIGHT
003D 00M340J063130 00M340J063130 ESCUTCHEON ESCUTCHEON
007D 00M339J257110 00M339J257110 LID TOP LID
013D 00M339J063130 00M339J063130 ESCUTCHEON ESCUTCHEON TOP LID
015D 00M339J202010 00M339J202010 NET NET ESCUTCHEON
002G 00M163J057220 00M163J057220 LEG LEG
(
CUPPER
)
906G 00M426T154010 00M426T154010 KNOB KNOB ID NO. SWITCH
J001 00MYJ04002550 00MYJ04002550 JACK ! MAINS INLET TYPE HF-301
J003 00MYJ01004760 00MYJ01004760 JACK NC3FDL-B-1
J004 00MYJ01004760 00MYJ01004760 JACK NC3FDL-B-1
J005 00MYT02011300 00MYT02011300 TERMINAL EW-2560T-LH-B
J006 00MYT02011300 00MYT02011300 TERMINAL EW-2560T-LH-B
J007 00MYT02011300 00MYT02011300 TERMINAL EW-2560T-LH-B
J008 00MYT02011300 00MYT02011300 TERMINAL EW-2560T-LH-B
J009 00MYT02011300 00MYT02011300 TERMINAL EW-2560T-LH-B
J010 00MYT02011300 00MYT02011300 TERMINAL EW-2560T-LH-B
J011 00MYT02011300 00MYT02011300 TERMINAL EW-2560T-LH-B
J012 00MYT02011300 00MYT02011300 TERMINAL EW-2560T-LH-B
J013 00MYT02011300 00MYT02011300 TERMINAL EW-2560T-LH-B
J014 00MYT02011300 00MYT02011300 TERMINAL EW-2560T-LH-B
J015 00MYP01001140 00MYP01001140 PLUG NC3MDL-B-1
J016 00MYP01001140 00MYP01001140 PLUG NC3MDL-B-1
J017 00MYT02011300 00MYT02011300 TERMINAL EW-2560T-LH-B
J018 00MYT02011300 00MYT02011300 TERMINAL EW-2560T-LH-B
J019 00MYT02011300 00MYT02011300 TERMINAL EW-2560T-LH-B
J020 00MYT02011300 00MYT02011300 TERMINAL EW-2560T-LH-B
L001 F N ns
p
00MTS40701010 TRANSF. # POWER TRANSF. FOR F
L001
/
K1G ns
p
00MTS40701020 TRANSF. # POWER TRANSF. FOR N
L001
/
N1G 00MTS40701020 00MTS40701020 TRANSF. # POWER TRANSF. FOR N
L001
/
U1B ns
p
00MTS40701030 TRANSF. # POWER TRANSF. FOR U
L002 00MFN21010050 00MFN21010050 EMI FILTER ! 0.18HX2 CHOKE COIL
L003 00MFC50160030 00MFC50160030 FERRITE CORE FERRITE CORE TFCK-16813
L004 00MFC50160030 00MFC50160030 FERRITE CORE FERRITE CORE TFCK-16813
L005 00MFC50160030 00MFC50160030 FERRITE CORE FERRITE CORE TFCK-16813
L006 00MFC50160030 00MFC50160030 FERRITE CORE FERRITE CORE TFCK-16813
P101 ns
p
ns
p
PWB ASSY MAIN PWB ASSY
P261 ns
p
ns
p
PWB ASSY FUNCTION SW PWB ASSY
P271 ns
p
ns
p
PWB ASSY FCBS PWB ASSY
P301 ns
p
ns
p
PWB ASSY 7 SEG LED PWB ASSY
P401 ns
p
ns
p
PWB ASSY UNBAL INPUT PWB ASSY
P801 ns
p
ns
p
PWB ASSY POWER SUPPLY PWB ASSY
P851 ns
p
ns
p
PWB ASSY RECT PWB ASSY
P871 ns
p
ns
p
PWB ASSY POWER SW PWB ASSY
PD71 ns
p
ns
p
PWB ASSY VR MODULE PWB ASSY
PF01 ns
p
ns
p
PWB ASSY FUSE PWB ASSY
PS01 ns
p
ns
p
PWB ASSY ID SW PWB ASSY
PS71 ns
p
ns
p
PWB ASSY MODE SW PWB ASSY
PU01 ns
p
ns
p
PWB ASSY U-PRO PWB ASSY
PU51 ns
p
ns
p
PWB ASSY R LED PWB ASSY
POS. NO.
71
