Marantz SC-7S2 - Page 68

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
MAIN PWB P101
(
00MWG340J501-
)
P101 C151 ns
p
00MOA226025Z0 ELECT. CAP. ROS-25V 220M-F3#PE-T2
P101 C152 ns
p
00MOA226025Z0 ELECT. CAP. ROS-25V 220M-F3#PE-T2
P101 C153 ns
p
00MOA226025Z0 ELECT. CAP. ROS-25V 220M-F3#PE-T2
P101 C154 ns
p
00MOA226025Z0 ELECT. CAP. ROS-25V 220M-F3#PE-T2
P101 C155 00MOF55220590 00MOF55220590 FILM CAP. 22PF 200V +-5% FAS
P101 C156 00MOF55220590 00MOF55220590 FILM CAP. 22PF 200V +-5% FAS
P101 C157 00MOF55220590 00MOF55220590 FILM CAP. 22PF 200V +-5% FAS
P101 C158 00MOF55220590 00MOF55220590 FILM CAP. 22PF 200V +-5% FAS
P101 C159 ns
p
00MOA226025Z0 ELECT. CAP. ROS-25V 220M-F3#PE-T2
P101 C160 ns
p
00MOA226025Z0 ELECT. CAP. ROS-25V 220M-F3#PE-T2
P101 C161 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M-5#PE-T2
P101 C162 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M-5#PE-T2
P101 C501 ns
p
00MOA227010R0 ELECT. CAP. ROA-10V 221M-H3#PE-T2
P101 C502 nsp 00MOA227010R0 ELECT. CAP. ROA-10V 221M-H3#PE-T2
P101 C507 ns
p
00MOA227016Z0 ELECT. CAP. ROS-16V 221M-H5#PE-T2
P101 C508 ns
p
00MOA227016Z0 ELECT. CAP. ROS-16V 221M-H5#PE-T2
P101 C513 ns
p
00MOA476016Z0 ELECT. CAP. ROS-16V 470M-G3#PE-T2
P101 C514 ns
p
00MOA476016Z0 ELECT. CAP. ROS-16V 470M-G3#PE-T2
P101 C515 ns
p
00MOA476016Z0 ELECT. CAP. ROS-16V 470M-G3#PE-T2
P101 C516 ns
p
00MOA476016Z0 ELECT. CAP. ROS-16V 470M-G3#PE-T2
P101 C517 ns
p
00MOA476016Z0 ELECT. CAP. ROS-16V 470M-G3#PE-T2
P101 C518 ns
p
00MOA476016Z0 ELECT. CAP. ROS-16V 470M-G3#PE-T2
P101 C519 ns
p
00MOA476016Z0 ELECT. CAP. ROS-16V 470M-G3#PE-T2
P101 C520 ns
p
00MOA476016Z0 ELECT. CAP. ROS-16V 470M-G3#PE-T2
P101 C521 ns
p
00MOA226025R0 ELECT. CAP. ROA-25V 220M-F3#PE-T2
P101 C522 ns
p
00MOA226025R0 ELECT. CAP. ROA-25V 220M-F3#PE-T2
P101 C523 ns
p
00MOA226025R0 ELECT. CAP. ROA-25V 220M-F3#PE-T2
P101 C524 ns
p
00MOA226025R0 ELECT. CAP. ROA-25V 220M-F3#PE-T2
P101 C525 00MOF56221540 00MOF56221540 FILM CAP. FPS-200V-221K
(
220PF 10%
)
P101 C526 00MOF56221540 00MOF56221540 FILM CAP. FPS-200V-221K
(
220PF 10%
)
P101 C527 00MOF56221540 00MOF56221540 FILM CAP. FPS-200V-221K
(
220PF 10%
)
P101 C528 00MOF56221540 00MOF56221540 FILM CAP. FPS-200V-221K
(
220PF 10%
)
P101 C529 ns
p
00MOA476016Z0 ELECT. CAP. ROS-16V 470M-G3#PE-T2
P101 C530 ns
p
00MOA476016Z0 ELECT. CAP. ROS-16V 470M-G3#PE-T2
P101 C531 ns
p
00MOA476016Z0 ELECT. CAP. ROS-16V 470M-G3#PE-T2
P101 C532 ns
p
00MOA476016Z0 ELECT. CAP. ROS-16V 470M-G3#PE-T2
P101 C533 ns
p
00MOA108025R0 ELECT. CAP. ROA-25V 102M-J7#PE-S1
P101 C534 ns
p
00MOA108025R0 ELECT. CAP. ROA-25V 102M-J7#PE-S1
P101 C535 ns
p
00MOA108025R0 ELECT. CAP. ROA-25V 102M-J7#PE-S1
P101 C536 ns
p
00MOA108025R0 ELECT. CAP. ROA-25V 102M-J7#PE-S1
P101 CE07 ns
p
00MOA106035Z0 ELECT. CAP. ROS-35V 100M-F3#PE-T2
P101 CE08 ns
p
00MOA106035Z0 ELECT. CAP. ROS-35V 100M-F3#PE-T2
P101 CE09 ns
p
00MOA106035Z0 ELECT. CAP. ROS-35V 100M-F3#PE-T2
P101 CE10 ns
p
00MOA106035Z0 ELECT. CAP. ROS-35V 100M-F3#PE-T2
P101 CE11 00MOF56221540 00MOF56221540 FILM CAP. FPS-200V-221K
(
220PF 10%
)
P101 CE12 00MOF56221540 00MOF56221540 FILM CAP. FPS-200V-221K
(
220PF 10%
)
P101 CE13 00MOF56221540 00MOF56221540 FILM CAP. FPS-200V-221K
(
220PF 10%
)
P101 CE14 00MOF56221540 00MOF56221540 FILM CAP. FPS-200V-221K
(
220PF 10%
)
P101 CE15 ns
p
00MOA476016Z0 ELECT. CAP. ROS-16V 470M-G3#PE-T2
P101 CE16 ns
p
00MOA476016Z0 ELECT. CAP. ROS-16V 470M-G3#PE-T2
P101 CE17 ns
p
00MOA476016Z0 ELECT. CAP. ROS-16V 470M-G3#PE-T2
P101 CE18 ns
p
00MOA476016Z0 ELECT. CAP. ROS-16V 470M-G3#PE-T2
P101 CE19 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M-5#PE-T2
P101 CE20 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M-5#PE-T2
P101 CE21 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M-5#PE-T2
P101 CE22 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M-5#PE-T2
P101 D111 ns
p
00MHD20002710 DIODE 1D3 1A/200V
P101 D112 ns
p
00MHD20002710 DIODE 1D3 1A/200V
P101 D113 ns
p
00MHD20002710 DIODE 1D3 1A/200V
P101 D114 ns
p
00MHD20002710 DIODE 1D3 1A/200V
P101 D115 ns
p
00MHD20002710 DIODE 1D3 1A/200V
P101 D116 ns
p
00MHD20002710 DIODE 1D3 1A/200V
P101 D117 ns
p
00MHD20002710 DIODE 1D3 1A/200V
P101 D118 ns
p
00MHD20002710 DIODE 1D3 1A/200V
P101 D119 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
P101 D121 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
POS. NO.
80
