Marantz SC-7S2 - Page 71

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
P101 RE26 ns
p
00MGD05391160 RES. 390 OHM +-5% 1/6W
P101 RE27 ns
p
00MGD05391160 RES. 390 OHM +-5% 1/6W
P101 RE28 ns
p
00MGD05391160 RES. 390 OHM +-5% 1/6W
P101 RE37 ns
p
00MGD05683160 RES. 68K OHM +-5% 1/6W
P101 RE38 ns
p
00MGD05683160 RES. 68K OHM +-5% 1/6W
P101 RE39 ns
p
00MGD05683160 RES. 68K OHM +-5% 1/6W
P101 RE40 ns
p
00MGD05683160 RES. 68K OHM +-5% 1/6W
P101 RR11 F N ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
P101 RR11
/
U1B ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
P101 RR14
/
K1G ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
P101 RR14
/
N1G ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
FUNCTION SW PWB P261
(
00MWG340J707-
)
P261 S261 00MSR01120070 00MSR01120070 ROTARY SW SRRSIC
FCBS PWB P271
(
00MWG340J709-
)
P271 C271 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
P271 C283 00MOF15102540 00MOF15102540 FILM CAP. 1000PF J 100V APSV
P271 C285 00MOF15102540 00MOF15102540 FILM CAP. 1000PF J 100V APSV
P271 C287 00MOF15102540 00MOF15102540 FILM CAP. 1000PF J 100V APSV
P271 D271 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
P271 D272 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
P271 D273 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
P271 D274 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
P271 D275 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
P271 J272 00MYJ11000500 00MYJ11000500 JACK 8PIN H-TYPE TCS7927-18-401
P271 J273 00MYJ11000500 00MYJ11000500 JACK 8PIN H-TYPE TCS7927-18-401
P271 L271 00MLY20240500 00MLY20240500 RELAY NA-24WK RELAY 2T 24V
P271 L272 00MLY20240500 00MLY20240500 RELAY NA-24WK RELAY 2T 24V
P271 L273 00MLY20240500 00MLY20240500 RELAY NA-24WK RELAY 2T 24V
P271 L274 00MLY20240500 00MLY20240500 RELAY NA-24WK RELAY 2T 24V
P271 L275 00MLY20240500 00MLY20240500 RELAY NA-24WK RELAY 2T 24V
P271 L276 00MFC90090010 00MFC90090010 FERRITE CORE ZBF503D-00
(
TA
)
-01
P271 Q272 00MHT600111B0 00MHT600111B0 TRS. KTA1267 PNP TRS. RANK=Y
P271 Q273 00MHW10006320 00MHW10006320 PHOTO UNIT PC-817 PHOTO CUPLER 1PAIR
P271 Q274 00MHT600111B0 00MHT600111B0 TRS. KTA1267 PNP TRS. RANK=Y
P271 Q275 00MBA20001000 00MBA20001000 TRS. DTC114ES/UN4211 10K,10K
P271 Q276 00MHT600111B0 00MHT600111B0 TRS. KTA1267 PNP TRS. RANK=Y
P271 Q277 00MBA20001000 00MBA20001000 TRS. DTC114ES/UN4211 10K,10K
P271 Q278 00MHT800921B0 00MHT800921B0 TRS. KTC3199 NPN TRS. RANK=Y
P271 Q279 00MHT600111B0 00MHT600111B0 TRS. KTA1267 PNP TRS. RANK=Y
P271 R271 ns
p
00MGD05101160 RES. 100 OHM +-5% 1/6W
P271 R272 ns
p
00MGD05472160 RES. 4.7K OHM +-5% 1/6W
P271 R273 ns
p
00MGD05472160 RES. 4.7K OHM +-5% 1/6W
P271 R274 ns
p
00MGD05472160 RES. 4.7K OHM +-5% 1/6W
P271 R276 ns
p
00MGD05222160 RES. 2.2K OHM +-5% 1/6W
P271 R277 ns
p
00MGD05561160 RES. 560 OHM +-5% 1/6W
P271 R280 ns
p
00MGD05472160 RES. 4.7K OHM +-5% 1/6W
P271 R281 ns
p
00MGD05223160 RES. 22K OHM +-5% 1/6W
P271 R282 ns
p
00MGD05223160 RES. 22K OHM +-5% 1/6W
P271 R283 ns
p
00MGD05472160 RES. 4.7K OHM +-5% 1/6W
P271 R284 ns
p
00MGD05223160 RES. 22K OHM +-5% 1/6W
P271 R292 ns
p
00MGD05222160 RES. 2.2K OHM +-5% 1/6W
P271 R293 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6W
P271 R294 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6W
P271 R295 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6W
P271 S271 00MSS02021610 00MSS02021610 SLIDE SW SSSU022-S06N1
7 SEG LED PWB P301
(
00MWG340J702-
)
P301 D301 00MHQ10106300 00MHQ10106300 DISPLAY NKR131S-B
P301 D302 00MHQ10106300 00MHQ10106300 DISPLAY NKR131S-B
P301 D303 00MHQ10106300 00MHQ10106300 DISPLAY NKR131S-B
P301 D304 00MHQ10106300 00MHQ10106300 DISPLAY NKR131S-B
P301 Q302 00MHC10142090 00MHC10142090 IC IC NJU3719L
P301 R308 ns
p
00MGD05561160 RES. 560 OHM +-5% 1/6W
P301 R309 ns
p
00MGD05561160 RES. 560 OHM +-5% 1/6W
P301 R310 ns
p
00MGD05561160 RES. 560 OHM +-5% 1/6W
P301 R311 ns
p
00MGD05561160 RES. 560 OHM +-5% 1/6W
P301 R312 ns
p
00MGD05561160 RES. 560 OHM +-5% 1/6W
P301 R313 ns
p
00MGD05561160 RES. 560 OHM +-5% 1/6W
